1. Main Information:
TM101JDHP01 is a 10.1" diagonal a-Si TFT-LCD display panel product from Tianma Microelectronics Co., Ltd.with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of -10 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are following: WLED Backlight . Based on its features, this model be applied to Industrial etc.
2. TIANMA TM101JDHP01 Mechanical Features:
| Panel Size : | 10.1 Inch |
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 1280(RGB)×800, WXGA | RGB Vertical Stripe | 0.0565×0.1695 mm | 0.1695×0.1695 mm [149PPI] |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 216.96×135.6 mm | - | 229.46×149.1 mm | 2.55/4.6 (Typ./Max.) mm |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle | 16:10 (W : H) | Landscape type | - |
| Fixation : | Without |
| Other Features : | Panel Cover | Weight | Surface |
| - | 180g (Typ.) | Hard coating |
3. TIANMA TM101JDHP01 Optical Features:
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
| 400 cd/m² (Typ.) | SFT, Normally Black, Transmissive | 800:1 (Typ.) (Transmissive) |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed |
| 85/85/85/85 (Typ.)(CR≥10) | Symmetry | 10/15 (Typ.)(Tr/Td) (ms) |
| Dispaly Color : | Color Temperature | Color Amount | White color Chromaticity |
| 7289K | 16.7M (8-bit) | X:0.300; Y:0.324 |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 52% | 72% | 54% |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks |
| 54% | 39% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Luminance Variation : | 1.25/1.33 (Typ./Max.)(9 points) |
4. TIANMA TM101JDHP01 Interface Features:
| Signal Electrical : | Current Input | Voltage Input | Consumption |
| 54.1/47.6/0.66/0.66mA (Typ.)(IDD/AIDD/IGH/IGL) | 3.3/11.0/23/-7.0V (Typ.)(VDD/AVDD/VGH/VGL) | - |
| Interface Features : | Position | Type | Interface |
| - | Connector | LVDS (1 ch, 8-bit) |
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| Vigorconn | F62240-H1210A | 1 pcs | 0.5 mm | 40 pins |
5. FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
