1. Main Information:
The TM057KBHG01 is a 5.7 inch diagonal a-Si TFT-LCD display panel product from Tianma Microelectronics Co., Ltd. with an integral WLED backlight system, without backlight driver, touchscreen 4-wire Resistive Touch. It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -30 ~ 80°C . It's general features are following: With Touch, WLED Backlight, Life ≥ 50K hours, U/D,L/R Reverse, Matte . Based on its features,this model be applied to Industrial etc.
2. TIANMA TM057KBHG01 Optical Details:
| Basic Information : | Luminance | 320 cd/m² (Typ.) | Contrast Ratio | 500 : 1 (Typ.) (Transmissive) |
| Good View at | 6 o'clock | Response Speed | 20 (Typ.)(Tr+Td) (ms) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive |
| Color Performance : | Chromaticity | Wx:0.320; Wy:0.360 | Support Color | 262K (6-bit) |
| Color Temperature | 5983K | White Uniformity | 1.25/1.33 (Typ./Max.)(9 points) |
| 1931 Color Gamlt : | NTSC Ratio | 53% | sRGB | 73% coverage |
| Adobe RGB | 56% coverage | DCI-P3 | 55% coverage |
| Rec.2020 | 40% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
3. TIANMA TM057KBHG01 Mechanical Details:
| Pixel Features : | Number of Pixel | 320(RGB)×240 [QVGA] | Arrangement | RGB Vertical Stripe |
| Dot Pitch(W×H) | 0.120×0.360 mm | Pixel Pitch(W×H) | 0.360×0.360 mm [70PPI] |
| Physical Size : | Active Viewing | 115.2(W)×86.4(H) mm | Overall Dim. | 144(W)×104.6(H) mm |
| Bezel Opening | 117.6(W)×88.8(H) mm | Overall Depth | 14.0 (Max.) mm |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 4:3 | Shape Style | - |
| Touchscreen : | TP Controller | Without touch controller | TP Interface | - |
| Touch Points | - | TP Technology | 4-wire Resistive Touch |
| Fixation : | Rear mounting poles (4-Φ2.6) |
| Other Detail : | Mass | TBD | Surface | Antiglare, Hard coating (3H) |
4. TIANMA TM057KBHG01 Lightting Details:
| Lamp Features: | Lamp Shape | 3 strings | Lamp Type | WLED | Position | Edge light type |
| Exchange | - | Amount | 5S3P | Life | 50K(Typ.) (Hours) |
| Lamp Electrical : | Input Current | 25mA (Typ.) | Input Voltage | 14.85/18.15V (Min./Max.) |
| Consumption | 1.238mW (Typ.) |
| Interface Features : | Position | - | Physical Type | Included in panel signal interface |
| Backlight Driver : | No |
5. FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
