NEC NL12876BC26-32D Application Details
| Basic Info : | Panel Brand | | Panel Model | NL12876BC26-32D |
| Diagonal Size | 15.3" | Application | |
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | - |
| Reliability : | Operating Temp. | -20 ~ 70 °C | Storage Temp. | -20 ~ 80 °C |
| RoHS State | | Vibration Rating | 1.2G (11.76 m/s²) |
NEC NL12876BC26-32D Mechanical Details
| Pixel Features : | Pixel Format | 1280(RGB)×768 [WXGA] | Dot Pitch | 0.087×0.261 mm (H×V) |
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.261×0.261 mm (H×V) [97PPI] |
| Mechanical Size : | Display Area | 334.08×200.45 mm (H×V) | Bezel Area | 336.2×202.8 mm (H×V) |
| Outline Dim. | 358×226 mm (H×V) | Outline Depth | 13.8/14.8 (Typ./Max.) mm |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 15:9 (H:V) | Shape Style | |
| Holes & Brackets : | Side mounting holes (4-M3) on left, right bezel |
| Other Features : | Weight | 1.10/1.20Kgs (Typ./Max.) | Surface | Antiglare, Hard coating (3H) |
NEC NL12876BC26-32D Optical Details
| Basic Information : | Brightness | 470 cd/m² (Typ.) | Contrast Ratio | 700:1 (Typ.) (Transmissive) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) | Optical Mode | SA-SFT, Normally Black, Transmissive |
| Viewing Direction | Symmetry | Response Time | 14/11 (Typ.)(Tr/Td) (ms) |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Color Numbers | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| Color Temperature | 6485K | White Uniformity | 1.10/1.30 (Typ./Max.)(5 points) |
| 1931 Color Gamlt : | NTSC Ratio | 41% | sRGB | 57% coverage |
| Adobe RGB | 43% coverage | DCI-P3 | 42% coverage |
| Rec.2020 | 30% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
NEC NL12876BC26-32D Backlight Details
| Back-light Features: | Lamp Shape | 4 strings | Lamp Type | WLED | Life Time | 70K(Typ.) (Hours) |
| Replacement | Replaceable (153LHS201) | Amount | 4 strings | Position | Edge light type |
| Lamp Electrical : | Voltage Input | 25.7/28.4/31.5V (Min./Typ./Max.) | Current Input | 70/77mA (Typ./Max.) |
| Interface Features : | Type | Connector | Position | - | Lamp Driver | No |
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| JST | SM10B-SHLS-TF(LF)(SN) | 1.0 mm | 10 pins | 1 pcs | BLE-10PINS-AANNCCCCNN |
NEC NL12876BC26-32D Interface Details
| Signal Systerm : | LVDS (1 ch, 6/8-bit) | Logic Voltage | - |
| Signal Electrical : | Voltage Input | 3.3V (Typ.) | Current Input | 550/900mA (Typ./Max.) |
| Interface Features : | Type | Connector | Position | - | |
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| HRS | DF14H-20P-1.25H | 1.25 mm | 20 pins | 1 pcs | LVDS-20P1C8B-080F |
