SP14Q002-A1 HITACHI 5.7 inch 320×240 140 cd/m² Storage Temperature: -20 ~ 60 °C INDUSTRIAL LCD DISPLAY

Brand Name : HITACHI

Model Number : SP14Q002-A1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 600PCS

Delivery Time : 1-3 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : SP14Q002-A1

BRAND : HITACHI

SIZE : 5.7INCH

RESOLUTION : 320×240 [QVGA] 70PPI

BRIGHTNESS : 140 cd/m²

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

HITACHI SP14Q002-A1 Application Features

Basic Information : Manufacturer Panel Model Panel Type Alias
  SP14Q002-A1 FSTN-LCD , LCM -
Environment : RoHS State Operating Temp. Storage Temp. Vibration Level
  0 ~ 50 °C -20 ~ 60 °C -
Used For :
Specific Features :



HITACHI SP14Q002-A1 Optical Features

Basic Information : Luminance (cd/m²) Viewing Angle (L/R/U/D) Response Time (ms)
140 (Typ.) 40 (Typ.)(CR≥2, Φ2-Φ1) 120/150 (Typ.)(Tr/Td)
Best View on Display Mode Contrast Ratio
6 o'clock STN, Black/White (Negative), Transmissive 25 : 1 (Typ.) (Transmissive)
Dispaly Color : Color Temperature Display Colors White Coordinate
- Monochrome



HITACHI SP14Q002-A1 Mechanical Features

Panel Size : 5.7"
Pixel Features : Pixel Format Pixel Configuration Pixel Pitch (mm) Dot Pitch (mm)
320×240 [QVGA] Rectangle 0.360×0.360 [70PPI] 0.360×0.360
Mechanical Size : Active Area (mm) Bezel Area (mm) Outline Dimension (mm) Outline Depth (mm)
115.185(H) × 86.385(V) 122.0(H) × 92.0(V) 167(H) × 109(V) 8.5/10.0 (Typ.Max.) mm
Outline Features : Form Factor Orientation Aspect Ratio Shape Style
Flat Rectangle Landscape type 4:3 (H:V)
Mounting : Face mounting holes (4-Φ3.5) on left, right bezel
Other Detail : Weight Panel Cover Treatment
- - Antiglare



HITACHI SP14Q002-A1 Electronics Features

Reverse Scan : No
Vertical Frequency : 75Hz
Driving Method : Duty: 1/240





HITACHI SP14Q002-A1 Backlight Features

Lamp Features: Type Position Quantity  Shape Life(Hours) Lamp Exchange
CCFL Edge light type 1 pcs Straight - -
CCFL Electrical : Voltage Supply Current Supply Power
300V (Typ.) 5.0±1.0mA
Operating Frequency Kick-off Voltage
70/85KHz (Typ./Max.) 1000V (Min.)(Ta=+25℃)
Interface Features : Position Backlight Driver Type
- No Connector
Interface Detail : Brand Model Pin Pitch Pin Amount Quantity Configuration
JAE IL-G-4S-S3C2 2.5 mm 4 pins 1 pcs BLL-4PINS-HNNL



HITACHI SP14Q002-A1 Interface Features

Panel Driving Electrical : Voltage Supply Current Supply Power
3.3/5.0V (Typ.)(VDD) - -
Interface Features : Position Signal Type
- Parallel Data (4-bit) FPC
FPC Detail : Brand Model Pin Pitch Pin Amount Quantity Configuration
    1.25 mm 14 pins 1 pcs PD-14P1C4B-010A



Q1:What's the quality of your LCD Panel?
A:Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2:What is your return and refund policy?
A:We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3:How long is the lead time?
A:The lead time is about 1-3 working days after receipt of payment.
Q4:How can I get the quotation?
A:Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
