NLT NL160120AC27-37 Application Features
| Basic Information : | Brand Name | Model Name | Type | Model Alias |
| | NL160120AC27-37 | a-Si TFT-LCD , LCM | - |
| Maximum Ratings : | RoHS | Operating Temperature | Storage Temperature | Vibration Level |
| | 0 ~ 60 °C | -20 ~ 60 °C |
NLT NL160120AC27-37 Mechanical Features
| Screen Size : | 21.3" |
| Pixel Features : | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
| 1600(RGB)×1200, UXGA | RGB Vertical Stripe | 0.090×0.270 mm | 0.270×0.270 mm [94PPI] |
| Mechanical Size : | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
| 432×324 mm | 438.2×330.0 mm | 457×350 mm | 21.5±0.5 mm |
| Outline Features : | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
| Flat Rectangle | 4:3 | Landscape type | |
| Other Spec : | Mass | Panel Cover | Surface Treatment |
| 2.70/2.98Kgs (Typ./Max.) | - | Antiglare, Hard coating (2H) |
| Holes & Brackets : | Side mounting holes (4-M3) on left, right bezel |
NLT NL160120AC27-37 Optical Features
| Basic Information : | Luminance | Work Mode | Contrast Ratio |
| 900 cd/m² (Typ.) | SFT, Normally Black, Transmissive | 1400:1 (Typ.) (Transmissive) |
| Good View at | Viewing Angle | Response Time |
| Symmetry | 88/88/88/88 (Typ.)(CR≥10) | 20/20 (Typ.)(Tr/Td) (ms) |
| Dispaly Color : | Color Temperature: | Support Color | Color Coordinate |
| 7502K | 16.7M (8-bit) | X:0.299; Y:0.315 |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 72% | 98% | 75% |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks |
| 75% | 54% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| White Uniformity : | 1.25 (Max.)(9 points) |
| Performance : | 3D Technology | Outdoor Visibility | Reflectance |
| - | Sunlight Readable | - |
NLT NL160120AC27-37 Backlight Features
| Back-light Features: | Type | Position | Life(Hours) | Amount | Shape | Replacement |
| WLED | Edge light type | 70K(Typ.) | - | - | - |
| Interface Features : | WLED Driver State | Physical Type | Interface Position |
| With LED Driver | Connector | - |
| Interface Detail | Brand Name | Model Name | Amount | Pins | Pin Pitch | Pin Configuration |
| HRS | DF3Z-10P-2H | 1 pcs | 10 pins | 2.0 mm | |
| JAE | IL-Z-9PL-SMTYE | 1 pcs | 9 pins | 1.25 mm | |
| WLED Driver Electrical : | Input Voltage | Input Current | Power Consumption |
| 12.0V (Typ.) | 4.2/5.8A (Typ./Max.) | - |
NLT NL160120AC27-37 Interface Features
| Signal Electrical : | Input Voltage | Input Current | Power Consumption |
| 12.0V (Typ.) | 500/700mA (Typ./Max.) | - |
| Interface Features : | Signal Type | Physical Type | Interface Position |
| LVDS (2 ch, 8-bit) | Connector | - |
| Interface Detail : | Brand Name | Model Name | Amount | Pins | Pin Pitch | Pin Configuration |
| HRS | DF19G-30P-1H(56) | 1 pcs | 30 pins | 1.0 mm | LVDS-30P2C8B-170B |
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
