TM050RBH02 TIANMA 5.0" 800(RGB)×480 250 cd/m² INDUSTRIAL LCD DISPLAY

Sapientia Display Co.,LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

TM050RBH02 TIANMA 5.0" 800(RGB)×480 250 cd/m² INDUSTRIAL LCD DISPLAY

  • 1
  • 2
  • 3

Brand Name : TIANMA

Model Number : TM050RBH02

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 3000PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : TM050RBH02

BRAND : TIANMA

SIZE : 5.0 inch

RESOLUTION : 800(RGB)×480 [WVGA] 188PPI

BRIGHTNESS : 250 cd/m² (Typ.)

Viewing Angle : 60/60/60/45 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C

Contact Now

TIANMA TM050RBH02 Application Features

Basic Information : Brand Model Type Model Alias
  TM050RBH02 a-Si TFT-LCD , LCM -
Reliability : RoHS Operating Temperature Storage Temperature Vibration Resistance
  -20 ~ 70 °C -30 ~ 80 °C -
Designed For :



Specific Features :




Remarks : down side FPC



TIANMA TM050RBH02 Mechanical Features

Panel Size : 5.0 inch
Pixel Features : Resolution Pixel Arrangement Dot Pitch (W×H) Pixel Pitch (W×H)
800(RGB)×480, WVGA RGB Vertical Stripe 0.045×0.135 mm 0.135×0.135 mm [188PPI]
Mechanical Size : Active Area (W×H) Bezel Area (W×H) Outline Dimension (W×H) Outline Depth
108×64.8 mm 111.1×67.9 mm 120.7×75.8 mm 4.65 (Max.) mm
Outline Features : Form Style Aspect Ratio Orientation Shape Style
Flat Rectangle 15:9 (W : H) Landscape type
Touchscreen : Touch Points TP Controller Signal Type Touch Tech
- With touch controller I²C PCAP
Other Features : Panel Cover Weight Surface
- TBD Antiglare



TIANMA TM050RBH02 Optical Features

Basic Information : Brightness Operating Mode Contrast Ratio
250 cd/m² (Typ.) TN, Normally White, Transmissive 450:1 (Typ.) (Transmissive)
Viewing Angle(L/R/U/D) Viewing Direction Response Speed
60/60/60/45 (Typ.)(CR≥10) 12 o'clock 20/20 (Typ.)(Tr/Td) (ms)
Dispaly Color : Color Temperature Color Amount White color Chromaticity
6638K 16.7M (8-bit) X:0.310; Y:0.330
1931 Color Gamlt : NTSC Ratio sRGB Coverage Adobe RGB Coverage
49% 68% 52%
DCI-P3 Coverage Rec.2020 Coverage Remarks
51% 37% sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Luminance Variation : 1.25/1.33 (Typ./Max.)(9 points)



TIANMA TM050RBH02 Electronics Features

Frame Rate : 60Hz
Reverse Scan : No
D-IC Detail : Built-in HX8264 + HX8664-B
Time Controller (T-CON) : Embedded T-CON



TIANMA TM050RBH02 Interface Features

Signal Electrical : Current Input Voltage Input Consumption
TBD 3.3V (Typ.) -
Voltage for Display Signals : 0≤VIL≤0.3VDD; 0.7VDD1≤VIH≤VDD
Interface Features : Position Type Interface
- FPC Parallel RGB (1 ch, 8-bit)
Signal Interface : Brand Model Amount Pin Pitch Pins Pin Assignment
    1 pcs   40 pins



TIANMA TM050RBH02 Backlight Features

Backlight Features: Type Position Shape Amount  Life(Hours) Replacement
WLED Edge light type Array 7S2P 20K(Typ.) -
WLED Electrical : Current Input Voltage Input Consumption
40mA (Typ.) 23.1V (Typ.) 0.93W (Typ.)
Interface Features : Position Type WLED Driver
- Included in panel signal interface

No





TIANMA TM050RBH02 Backlight Features

Backlight Features: Type Position Shape Amount  Life(Hours) Replacement
WLED Edge light type Array 7S2P 20K(Typ.) -
WLED Electrical : Current Input Voltage Input Consumption
40mA (Typ.) 23.1V (Typ.) 0.93W (Typ.)
Interface Features : Position Type WLED Driver
- Included in panel signal interface No



 FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
