G238HCJ-L02 Innolux 23.8" 1920(RGB)×1080 450 cd/m² INDUSTRIAL LCD DISPLAY

Sapientia Display Co.,LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

G238HCJ-L02 Innolux 23.8" 1920(RGB)×1080 450 cd/m² INDUSTRIAL LCD DISPLAY

  • 1
  • 2
  • 3

Brand Name : INNOLUX

Model Number : G238HCJ-L02

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 100PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : G238HCJ-L02

BRAND : INNOLUX

SIZE : 23.8 inch

BRIGHTNESS : 450CD/M2

Lamp Type : WLED

RESOLUTION : 1920(RGB)×1080 [FHD] 92PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

Innolux G238HCJ-L02 Application Details

Basic Detail :
Manufacturer

G238HCJ-L02Model Name
Panel Type
a-Si TFT-LCD , LCM
Another Name
-
Panel Size
Designed For
Maximum Ratings :
OP Temperature
0 ~ 60 °C
ST Temperature
-20 ~ 60 °C
RoHS

1.5G (14.7 m/s²)Vibration Level



Innolux G238HCJ-L02 Optical Details

Basic Detail :
Luminance
450 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (Transmissive)
Good View at
Symmetry
Response Speed
8/7 (Typ.)(Tr/Td) ms
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
AAS, Normally Black, Transmissive
Color Performance :
Chromaticity
Wx:0.313; Wy:0.329
Support Color
16.7M (8-bit)
Color Temperature
6485K
White Variation
1.33 (Max.)(9 points)
1931 Color Gamlt :
NTSC Ratio
75%
sRGB
98% coverage
Adobe RGB
76% coverage
DCI-P3
78% coverage
Rec.2020
56% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



Innolux G238HCJ-L02 Mechanical Details

Pixel Features :
Number of Pixel
1920(RGB)×1080, FHD
Arrangement
RGB Vertical Stripe
Dot Pitch(W×H)
0.0915×0.2745 mm
Pixel Pitch(W×H)
0.2745×0.2745 mm [92PPI]
Physical Size :
Active Viewing
527.04(W)×296.46(H) mm
Overall Dim.
540.24(W)×315.66(H) mm
Bezel Opening
530.2(W)×299.6(H) mm
Overall Depth
11.45/11.95 (Typ./Max.) mm
Outline Features :
Form Shape
Flat Rectangle
Orientation
Landscape type
Aspect Ratio(W:H)
16:9
Shape Style

Fixation :
Side mounting holes (4-M3) on left, right bezel
Other Detail :
Mass
2.71Kgs (Typ.)
Surface
Antiglare (Haze 25%), Hard coating (3H)



Innolux G238HCJ-L02 Interface Detail

Signal Electrical :
Input Current
0.36/0.45A (Typ./Max.)
Input Voltage
5.0±0.5V
Consumption
3.52/4.18W (Typ./Max.)
Signal Interface
LVDS (2 ch, 8-bit)
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
FOXCONN
1.0 mm
30 pins
1 pcs



Innolux G238HCJ-L02 Lightting Details

Lamp Features :
Lamp Type
WLED
Amount
-
Position
Edge light type
Exchange
-
Lamp Shape
-
Lamp Life
30K(Min.) (Hours)
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment

CI4310M1HR0-NH

10 pins
1 pcs

Backlight Driver :
With LED Driver
Driver Electrical :
Input Voltage
12±1.2V
Input Current
1.6A (Typ.)
Consumption
18.7W (Typ.)



Innolux G238HCJ-L02 Packing Details

Package Box : Amount Size (L×W×H) Weight
12 pcs / box 28.8 Kgs 620×348×430 mm



  FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
