P101KDA-AB0 Innolux 10.1" 1200(RGB)×1920 440 cd/m² INDUSTRIAL LCD DISPLAY

Name: P101KDAAB0 Innolux 101quot 1200RGB1920 440 cdm INDUSTRIAL LCD DISPLAY
Brand: INNOLUX
Price: 1 USD

Buy cheap P101KDA-AB0 Innolux 10.1" 1200(RGB)×1920 440 cd/m² INDUSTRIAL LCD DISPLAY product

Brand Name : INNOLUX

Model Number : P101KDA-AB0

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 1000PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : P101KDA-AB0

BRAND : INNOLUX

SIZE : 10.1INCH

BRIGHTNESS : 440 cd/m² (Typ.)

Lamp Type : WLED

RESOLUTION : 1200(RGB)×1920 [WUXGA] 225PPI

VIEWING ANGLEG : 80/80/80/80 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C

Contact Now

Innolux P101KDA-AB0 Application Details

Basic Detail :	Manufacturer		Model Name	P101KDA-AB0
	Panel Type	a-Si TFT-LCD , LCM	Another Name	-
	Panel Size	10.1 inch	Designed For
Maximum Ratings :	OP Temperature	-10 ~ 60 °C	ST Temperature	-20 ~ 70 °C

Innolux P101KDA-AB0 Optical Details

Basic Information :	Luminance	440 cd/m² (Typ.)	Contrast Ratio	1000 : 1 (Typ.) (Transmissive)
	Good View at	Symmetry	Response Speed	25 (Typ.)(Tr+Td) (ms)
	Viewing Angle	80/80/80/80 (Typ.)(CR≥10)	Operating Mode	AAS, Normally Black, Transmissive
Color Performance :	Chromaticity	Wx:0.313; Wy:0.329	Support Color	16.7M (8-bit)
Color Performance :	Color Temperature	6485K	White Uniformity	1.25/1.33 (Typ./Max.)(9 points)

Innolux P101KDA-AB0 Mechanical Details

Pixel Features :	Number of Pixel	1200(RGB)×1920 [WUXGA]	Arrangement	RGB Vertical Stripe
Pixel Features :	Dot Pitch(W×H)	0.0376×0.1128 mm	Pixel Pitch(W×H)	0.1128×0.1128 mm [225PPI]
Physical Size :	Active Viewing	135.36(W)×216.576(H) mm	Overall Dim.	143(W)×227.926(H) mm
Physical Size :	Bezel Opening	-	Overall Depth	2.5/4.4 (Typ./Max.) mm
Outline Features :	Form Shape	Flat Rectangle	Orientation	Portrait type
Outline Features :	Aspect Ratio(W:H)	10:16	Shape Style
Fixation :	Without
Other Detail :	Mass	144g (Max.)	Surface	Glare (Haze 0%), Hard coating (3H)

Innolux P101KDA-AB0 Interface Details

Signal Electrical :	Input Current	0.15A (Typ.)		Input Voltage	3.3V (Typ.)
Signal Electrical :	Consumption	0.5W (Max.)	Signal Interface	MIPI (4 data lanes)
Interface Features :	Position	-	Physical Type	Connector
Signal Interface :	Brand	Model	Amount	Pin Pitch	Pin Amount	Pin Assignment
Signal Interface :	I-PEX	20718-051E-01	1 pcs	0.3 mm	51 pins

Innolux P101KDA-AB0 Lightting Details

Lamp Features:	Lamp Shape	4 strings	Lamp Type	WLED	Position	Edge light type
Lamp Features:	Exchange	-	Amount	4 strings	Life	15K(Min.) (Hours)
Lamp Electrical :	Input Current	21mA (Typ.)		Input Voltage
Lamp Electrical :	Consumption	1.99/2.06W (Typ./Max.)
Interface Features :	Position	-	Physical Type	Included in panel signal interface
Backlight Driver :	No

nnolux P101KDA-AB0 Packing Details

Package Box :	Amount	Size (L×W×H)	Weight
Package Box :	36 pcs / box	590×390×320 mm	-

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
