LC430EUE-FHM2 LG Display 43" 1920(RGB)×1080 300cd/m2 INDUSTRIAL LCD DISPLAY 51PPI

Name: LC430EUEFHM2 LG Display 43quot 1920RGB1080 300cdm2 INDUSTRIAL LCD DISPLAY 51PPI
Brand: LG Display
Price: 1 USD

Buy cheap LC430EUE-FHM2 LG Display 43" 1920(RGB)×1080 300cd/m2 INDUSTRIAL LCD DISPLAY 51PPI product

Brand Name : LG Display

Model Number : LC430EUE-FHM2

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 100PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LG Display

SIZE : 43 inch

BRIGHTNESS : 300CD/M2

Lamp Type : WLED

RESOLUTION : 1920(RGB)×1080, FHD, 51PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG Display LC430EUE-FHM2 Application Details

Basic Info :	Panel Brand		Panel Model	LC430EUE-FHM2
	Diagonal Size	43"	Application
	Panel Type	a-Si TFT-LCD , LCM	Model Alias	LC430EUE (FH)(M2)
Reliability :	Operating Temp.	0 ~ 50 °C	Storage Temp.	-20 ~ 60 °C

LG Display LC430EUE-FHM2 Mechanical Details

Pixel Features :	Pixel Format	1920(RGB)×1080 [FHD]	Dot Pitch	0.1634×0.4902 mm (H×V)
Pixel Features :	Configuration	RGB Vertical Stripe	Pixel Pitch	0.4902×0.4902 mm (H×V) [51PPI]
Mechanical Size :	Display Area	941.184×529.416 mm (H×V)	Bezel Area	945.8×533.87 mm (H×V)
Mechanical Size :	Outline Dim.	973×565.8 mm (H×V)	Outline Depth	28.6 (Typ.) mm
Outline Features :	Form Factor	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio	16:9 (H:V)	Shape Style
Other Features :	Weight	7.00/7.35Kgs (Typ./Max.)	Surface	Antiglare (Haze 1%), Hard coating (3H)

LG Display LC430EUE-FHM2 Optical Details

Basic Information :	Brightness	300 cd/m² (Typ.)	Contrast Ratio	1200:1 (Typ.) (Transmissive)
	Viewing Angle	89/89/89/89 (Min.)(CR≥10)	Optical Mode	IPS, Normally Black, Transmissive
	Viewing Direction	Symmetry	Response Time	6 (Typ.)(G to G) (ms)
Color Performance :	Chromaticity	Wx:0.281; Wy:0.288	Color Numbers	16.7M (8-bit)
Color Performance :	Color Temperature	9966K	White Uniformity	1.54 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio	72%	sRGB	97% coverage
	Adobe RGB	74% coverage	DCI-P3	75% coverage
	Rec.2020	54% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LC430EUE-FHM2 Backlight Details

Back-light Features:	Lamp Shape	-	Lamp Type	WLED	Life Time	30K(Min.) (Hours)
Back-light Features:	Replacement	-	Amount	-	Position	Direct light type
Lamp Electrical :	Voltage Input	120.5/140.0V (Typ./Max.)		Current Input	180mA (Typ.)
Lamp Electrical :	Consumption	43.4/50.4W (Typ./Max.)
Interface Features :	Type	Connector	Position	-	Lamp Driver	No
Interface Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Interface Detail :	YEONHO	SMH200-H07M	2.0 mm	7 pins	1 pcs	BLE-7PINS-CNANCNA

LG Display LC430EUE-FHM2 Interface Details

Signal Systerm :	LVDS (2 ch, 8-bit)			Logic Voltage	-
Signal Electrical :	Voltage Input	12.7V (Typ.)		Current Input	350/450mA (Typ.)
Signal Electrical :	Consumption	4.4/5.8W (Typ./Max.)
Interface Features :	Type	Connector	Position
Connector Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Connector Detail :	JAE	FI-RXE51S-HF	0.5 mm	51 pins	1 pcs

LG Display LC430EUE-FHM2 Carton Details

Package Carton :	Amount	Net Weight	Carton Size (L×W×H)
Package Carton :	26 pcs / box	-	1300×1140×746 mm

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
