LB213QX1-SL01 LG Display 23.1" 2048(RGB)×1536 1000 cd/m² INDUSTRIAL LCD DISPLAY

Name: LB213QX1SL01 LG Display 231quot 2048RGB1536 1000 cdm INDUSTRIAL LCD DISPLAY
Brand: LG DISPLAY
Price: 1 USD

Buy cheap LB213QX1-SL01 LG Display 23.1" 2048(RGB)×1536 1000 cd/m² INDUSTRIAL LCD DISPLAY product

Brand Name : LG DISPLAY

Model Number : LB213QX1-SL01

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 300PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LB213QX1-SL01

BRAND : LG DISPLAY

SIZE : 23.1INCH

BRIGHTNESS : 1000CD/M2

Lamp Type : WLED

RESOLUTION : 2048(RGB)×1536 [QXGA] 120PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG Display LB213QX1-SL01 Application Details

Basic Information :	Brand LB213QX1-SL01Model Type a-Si TFT-LCD , LCM Used For 21.3 inchScreen Size Alias LB213QX1 (SL)(01)
Environment :	Storage Temp. -20 ~ 60 °C Operating Temp. 0 ~ 50 °C

LG Display LB213QX1-SL01 Mechanical Details

Pixel Features :	Resolution 2048(RGB)×1536, QXGA Dot Pitch(mm) 0.0705×0.2115 (H×V) Pixel Format RGB Vertical Stripe Pixel Pitch(mm) 0.2115×0.2115 (H×V) [120PPI]
Mechanical Size :	Active Area(mm) 433.152(H) × 324.864(V) Bezel Area(mm) 438.2(H) × 330.0(V) Outline Dim.(mm) 457(H) × 350(V) Depth(mm) 22.3/24.8 (Typ./Max.)
Outline Features :	Form Style Flat Rectangle Shape Style Aspect Ratio 4:3 (H:V) Orientation Landscape type
Mounting :	Side mounting holes (4-M3) on left, right bezel
Other Spec :	Weight 2.32/2.44Kgs (Typ./Max.) Treatment Antiglare, Hard coating (3H)

LG Display LB213QX1-SL01 Optical Details

Basic Information :	Luminance(cd/m²) 1000 (Typ.) Contrast Ratio 1300:1 (Typ.) (Transmissive) Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Display Mode IPS, Normally Black, Transmissive Best View on Symmetry Response(ms) 14 (Typ.)(G to G)
Color Performance :	White Coordinate Wx:0.302; Wy:0.336 Display Colors 1.07B (10-bit) Color Temperature 7012K White Uniformity 1.33 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio 73% sRGB 96% coverage Adobe RGB 74% coverage DCI-P3 76% coverage Rec.2020 54% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance :	Outdoor Visibility Sunlight Readable Transmissivity -

LG Display LB213QX1-SL01 Interface Detail

Signal Electrical :	Voltage Supply 12.0V (Typ.) Current Supply 0.47/0.64A (Typ./Max.) Consumption 5.6/7.35W (Typ./Max.)
Signal Type :	LVDS (4 ch, 10-bit) Logic Voltage -
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Quantity Pin Configuration UJU IS050-C51B-C39-C 0.5 mm 51 pins 1 pcs UJU IS050-C41B-C39-C 0.5 mm 41 pins 1 pcs

LG Display LB213QX1-SL01 Backlight Details

Backlight Features :	Type WLED Quantity - Position Edge light type Replacement - Shape - Life Time 50K(Min.) (Hours)
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Quantity Pin Configuration YEONHO 20022WR-H12B2 2.0 mm 12 pins 1 pcs
Backlight Driver :	With LED Driver
Driver Electrical :	Voltage Supply 24.0±2.4V Current Supply 1.78/2.31A (Typ./Max.) Consumption 42.72/55.44W (Typ./Max.)

LG Display LB213QX1-SL01 Packing Details

Package Box :	Quantity	Weight	Box Size
Package Box :	6 pcs / box	-	553×315×408 mm (L×W×H)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
