LM270WQ3-SLA1 LG Display 27.0" 2560(RGB)×1440 350 cd/m² INDUSTRIAL LCD DISPLAY

Name: LM270WQ3SLA1 LG Display 270quot 2560RGB1440 350 cdm INDUSTRIAL LCD DISPLAY
Brand: LG DISPLAY
Price: 1 USD

Buy cheap LM270WQ3-SLA1 LG Display 27.0" 2560(RGB)×1440 350 cd/m² INDUSTRIAL LCD DISPLAY product

Brand Name : LG DISPLAY

Model Number : LM270WQ3-SLA1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 600PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LM270WQ3-SLA1

BRAND : LG DISPLAY

SIZE : 27.0"inch

BRIGHTNESS : 350CD/M2

Lamp Type : WLED

RESOLUTION : 2560(RGB)×1440 [Quad-HD] 108PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG Display LM270WQ3-SLA1 Application Details

Basic Detail :	Manufacturer LM270WQ3-SLA1Model Name Panel Type a-Si TFT-LCD , LCM Another Name LM270WQ3 (SL)(A1) Panel Size 27.0 inch Designed For
Maximum Ratings :	OP Temperature 0 ~ 50 °C ST Temperature -20 ~ 60 °C

LG Display LM270WQ3-SLA1 Optical Details

Basic Detail :	Luminance 350 cd/m² (Typ.) Contrast Ratio 1000:1 (Typ.) (Transmissive) Good View at Symmetry Response Speed 6 (Typ.)(G to G) ms Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Operating Mode AH-IPS, Normally Black, Transmissive
Color Performance :	Chromaticity Wx:0.313; Wy:0.329 Support Color 1.07B (8-bit + Hi-FRC) Color Temperature 6485K White Variation 1.33 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio 104% sRGB 100% coverage Adobe RGB 99% coverage DCI-P3 94% coverage Rec.2020 77% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LM270WQ3-SLA1 Mechanical Details

Pixel Features :	Number of Pixel 2560(RGB)×1440, Quad-HD Arrangement RGB Vertical Stripe Dot Pitch(W×H) 0.0777×0.2331 mm Pixel Pitch(W×H) 0.2331×0.2331 mm [108PPI]
Physical Size :	Active Viewing 596.736(W)×335.664(H) mm Overall Dim. 630(W)×368.2(H) mm Bezel Opening 602.0(W)×340.4(H) mm Overall Depth 13.3/18.5 (Typ./Max.) mm
Outline Features :	Form Shape Flat Rectangle Orientation Landscape type Aspect Ratio(W:H) 16:9 Shape Style Normal bezel
Fixation :	Side mounting holes
Other Detail :	Mass 3.60/3.78Kgs (Typ./Max.) Surface Antiglare, Hard coating (3H)

LG Display LM270WQ3-SLA1 Interface Detail

Signal Electrical :	Input Current 1.15/1.5A (Typ./Max.) Input Voltage 12.0V (Typ.) Consumption 13.8/17.94W (Typ./Max.) Signal Interface LVDS (4 ch, 10-bit)
Interface Features :	Position ConnectorType
Interface Detail :	Brand Model Pitch Pins Amount Pin Assignment UJU IS050-C51B-C39-A 0.5 mm 51 pins 1 pcs UJU IS050-C41B-C39-A 0.5 mm 41 pins 1 pcs

LG Display LM270WQ3-SLA1 Lightting Details

Lamp Features :	Lamp Type GB-r LED Amount - Position Edge light type Exchange - Lamp Shape - Lamp Life 30K(Min.) (Hours)
Lamp Electrical :	Input Voltage 62/62V (Typ.)(Green/Blue) Input Current 105/65mA (Typ.)(Green/Blue) Consumption 42.2/45.0W (Typ./Max.)
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Amount Pin Assignment E&T H401K-D12N-12B 2.0 mm 12 pins 1 pcs BLE-12PINS-CCAACCCCAACC
Backlight Driver :	No

LG Display LM270WQ3-SLA1 Packing Details

Package Box :	Amount	Size (L×W×H)	Weight
Package Box :	8 pcs / box	-	355×700×430 mm
