LM190WX2-TLK1 LG Display 19.0" 1440(RGB)×900 250 cd/m² INDUSTRIAL LCD DISPLAY

Brand Name : LG DISPLAY

Model Number : LM190WX2-TLK1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 600PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LM190WX2-TLK1

BRAND : LG DISPLAY

SIZE : 19.0 inch

BRIGHTNESS : 250CD/M2

Lamp Type : WLED

RESOLUTION : 1440(RGB)×900 [WXGA+] 89PPI

VIEWING ANGLEG : 85/85/75/85 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG Display LM190WX2-TLK1 Application Features

Basic Information : Brand Name Model Name Type Model Alias
  LM190WX2-TLK1 a-Si TFT-LCD , LCM LM190WX2 (TL)(K1)
Maximum Ratings : RoHS Operating Temperature Storage Temperature Vibration Level
  0 ~ 50 °C -20 ~ 60 °C



LG Display LM190WX2-TLK1 Mechanical Features

Screen Size : 19.0"
Pixel Features : Pixel Number Pixel Format Dot Pitch (H×V) Pixel Pitch (H×V)
1440(RGB)×900, WXGA+ RGB Vertical Stripe 0.0945×0.2835 mm 0.2835×0.2835 mm [89PPI]
Mechanical Size : Display Area (H×V) Bezel Opening (H×V) Overall Dimension (H×V) Overall Depth
408.24×255.15 mm 412.2×259.0 mm 428×278 mm 8.6/10.7 (Typ./Max.) mm
Outline Features : Form Shape Aspect Ratio (H:V) Orientation Shape Style
Flat Rectangle 16:10 Landscape type Normal bezel
Other Spec : Mass Panel Cover Surface Treatment
1.40/1.47Kgs (Typ./Max.) - Antiglare, Hard coating (3H)
Holes & Brackets : Side mounting holes (4-M3) on left, right bezel



LG Display LM190WX2-TLK1 Optical Features

Basic Information : Luminance Work Mode Contrast Ratio
250 cd/m² (Typ.) TN, Normally White, Transmissive 1000:1 (Typ.) (Transmissive)
Good View at Viewing Angle Response Time
6 o'clock 85/85/75/85 (Typ.)(CR≥10) 1.3/3.7 (Typ.)(Tr/Td) (ms)
Dispaly Color : Color Temperature: Support Color Color Coordinate
6485K 16.7M (8-bit) X:0.313; Y:0.329
1931 Color Gamlt : NTSC Ratio sRGB Coverage Adobe RGB Coverage
72% 93% 72%
DCI-P3 Coverage Rec.2020 Coverage Remarks
75% 54% sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
White Uniformity : 1.33 (Max.)(9 points)



LG Display LM190WX2-TLK1 Backlight Features

Back-light Features: Type Position Life(Hours) Amount  Shape Replacement
WLED Edge light type (Right side) 30K(Min.) 13S2P 2 strings -
WLED Electrical : Input Voltage Input Current Power Consumption
39.0±1.6V 90/95mA (Typ./Max.) 7.0/7.5W (Typ./Max.)
Interface Features : WLED Driver State Physical Type Interface Position
No Connector
Interface Detail Brand Name Model Name Amount Pins Pin Pitch Pin Configuration
JST SM06B-SHJH(HF) 1 pcs 6 pins 1.0 mm BLE-6PINS-CNAANC



LG Display LM190WX2-TLK1 Interface Features

Signal Electrical : Input Voltage Input Current Power Consumption
5.0V (Typ.) 840±130mA 4.2/4.85W (Typ./Max.)
Interface Features : Signal Type Physical Type Interface Position
LVDS (2 ch, 8-bit) Connector
Interface Detail : Brand Name Model Name Amount Pins Pin Pitch Pin Configuration
UJU IS100-L30O-C23 1 pcs 30 pins 1.0 mm LVDS-30P2C8B-160C



LG Display LM190WX2-TLK1 Packing Features

Package Box : Amount Weight Size (L×W×H)
12 pcs / box - 350×300×470 mm (L×W×H)



FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
