LB043WV2-SD01 LG Display 4.3" 480(RGB)×800, WVGA 217PPI 600 cd/m² INDUSTRIAL LCD DISPLAY

  • 1
  • 2
  • 3

Brand Name : LG DISPLAY

Model Number : LB043WV2-SD01

Certification : ISO9001

Place of Origin : CHINA

MOQ : 1PCS

Payment Terms : TT/PAYPAL/WESTERN UNION/ESCROWS

Delivery Time : 1-2DAYS

Packaging Details : STANDARD PACKING

Brand : LG DISPLAY

Diagonal Size : 4.3"

Resolution : 480(RGB)×800, WVGA 217PPI

Luminance : 600 cd/m² (Typ.)

Outline : 60.06(H)×102.97(V) ×2.1(D) mm

Viewing Angle : 80/80/80/80 (Typ.)(CR≥10)

Interface Type : Parallel RGB (1 ch, 8-bit) + SPI , 50 pins Connector

Environment : Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C

Contact Now

LG Display LB043WV2-SD01 Mechanical Details

Pixel Features :
Resolution
480(RGB)×800, WVGA
Dot Pitch(mm)
0.039×0.117 (H×V)
Pixel Format
RGB Vertical Stripe
Pixel Pitch(mm)
0.117×0.117 (H×V) [217PPI]
Mechanical Size :
Active Area(mm)
56.16(H) × 93.6(V)
Bezel Area(mm)
-
Outline Dim.(mm)
60.06(H) × 102.97(V)
Depth(mm)
1.95±0.15
Outline Features :
Form Style
Flat Rectangle
Shape Style

Aspect Ratio
3:5 (H:V)
Orientation
Portrait type
Other Spec :
Weight
32.5±3.3g
Treatment
-



LG Display LB043WV2-SD01 Optical Details

Basic Information :
Luminance(cd/m²)
600 (Typ.)
Contrast Ratio
1000:1 (Typ.) (Transmissive)
Viewing Angle
80/80/80/80 (Typ.)(CR≥10)
Display Mode
IPS, Normally Black, Transmissive
Best View on
Symmetry
Response(ms)
40 (Typ.)(Tr+Td)
Color Performance :
White Coordinate
Wx:0.310; Wy:0.330
Display Colors
16.7M (8-bit)
Color Temperature
6638K
White Uniformity
1.25/1.43 (Typ./Max.)(9 points)
1931 Color Gamut :
NTSC Ratio
70%
sRGB
91% coverage
Adobe RGB
70% coverage
DCI-P3
73% coverage
Rec.2020
52% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



LG Display LB043WV2-SD01 Interface Detail

Signal Electrical :
Voltage Supply
1.8/2.8/2.8V (Typ.)(IOVCC/VCC/VCI)
Current Supply
-
Consumption
106.4/198mW (Typ./Max.)
Signal Type :
Parallel RGB (1 ch, 8-bit) + SPI
Logic Voltage
-0.3≤VIL≤0.2IOVCC; 0.8IOVCC≤VIH≤IOVCC
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Quantity
Pin Configuration
LS Mtron
GB042-50P-H10-E3000
0.4 mm
50 pins
1 pcs



LG Display LB043WV2-SD01 Backlight Details

Backlight Features :
Type
WLED
Quantity
5S2P
Position
Edge light type
Replacement
-
Shape
2 strings
Life Time
15K(Min.) (Hours)
Lamp Electrical :
Voltage Supply

Current Supply
20mA (Typ.)
Interface Features :
Position
-
Type
Included in signal interface
Backlight Driver :
No



 whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 56.16(W)×93.6(H) mm, outline size of 60.06(W)×102.97(H)×2.1(D) mm, net weight of 32.5±3.3g. As a IPS, Normally Black, Transmissive LCM product, LB043WV2-SD01 can provides 600 cd/m² display brightness 1000:1 transimissive contrast ratio, 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 40 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 70% (NTSC). This product adopted 5S2P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 15K hours, external backlight driver is additionally needed. LB043WV2-SD01 utilizes Parallel RGB (1 ch, 8-bit) + SPI as it's signal inputting systerm, which connected by 50 pins Connector with power supply voltage of 1.8/2.8/2.8V (Typ.)(IOVCC/VCC/VCI). It's typical vertical frame rate (Fv) is 60Hz. For more latest product detail of LB043WV2-SD01 We strongly recommend that you should refer to datasheet listed on Panelook.com or contact with LG Display or it's distributor.
