KCB104VG2BA-A21 Kyocera 10.4INCH LCM 640×480RGB 150NITS CCFL INDUSTRIAL LCD DISPLAY

Name: KCB104VG2BAA21 Kyocera 104INCH LCM 640480RGB 150NITS CCFL INDUSTRIAL LCD DISPLAY
Brand: Kyocera
Price: 1 USD

Buy cheap KCB104VG2BA-A21 Kyocera 10.4INCH LCM 640×480RGB 150NITS CCFL INDUSTRIAL LCD DISPLAY product

Brand Name : Kyocera

Model Number : KCB104VG2BA-A21

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW

Supply Ability : 100PCS

Delivery Time : 1-2day

Packaging Details : STANDARD PACKING

MODEL NUMBER : KCB104VG2BA-A21

BRAND : Kyocera

RESOLUTION : 640×480RGB

SIZE : 10.4INCH

BRIGHTNESS : 150 cd/m² (Typ.)

Type : CSTN-LCD , LCM

Light Source : CCFL [2 pcs] , 60K hours , Optional

TEMPERATURE RANGE : Operating Temperature: 0 ~ 40 °C

Contact Now

Kyocera KCB104VG2BA-A21 Application Details

Basic Info :	Panel Brand		Panel Model	KCB104VG2BA-A21
	Diagonal Size	10.4"	Application
	Panel Type	CSTN-LCD , LCM	Model Alias	-
Reliability :	Operating Temp.	0 ~ 40 °C	Storage Temp.	-20 ~ 60 °C
Reliability :	RoHS State		Vibration Rating

Kyocera KCB104VG2BA-A21 Mechanical Details

Pixel Features :	Pixel Format	640(RGB)×480 [VGA]	Dot Pitch	0.110×0.330 mm (H×V)
Pixel Features :	Configuration	RGB Vertical Stripe	Pixel Pitch	0.330×0.330 mm (H×V) [76PPI]
Mechanical Size :	Display Area	211.2×158.4 mm (H×V)	Bezel Area	217.2×164.4 mm (H×V)
Mechanical Size :	Outline Dim.	264×183 mm (H×V)	Outline Depth	8.5±0.5 mm
Outline Features :	Form Factor	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio	4:3 (H:V)	Shape Style
Holes & Brackets :	Face mounting holes (4-R1.7)
Other Features :	Weight	540g (Typ.)	Surface	Antiglare

Kyocera KCB104VG2BA-A21 Optical Details

Basic Information :	Brightness	150 cd/m² (Typ.)	Contrast Ratio	20:1 (Typ.) (Transmissive)
	Viewing Angle	45/45/35/20 (Typ.)(CR≥2)	Optical Mode	STN, Normally Black, Transmissive
	Viewing Direction	-	Response Time	16/80 (Typ.)(Tr/Td) (ms)
Color Performance :	Chromaticity	Wx:0.310; Wy:0.330	Color Numbers	Color
Color Performance :	Color Temperature	6638K	White Uniformity	-
1931 Color Gamlt :	NTSC Ratio	39%	sRGB	55% coverage
	Adobe RGB	41% coverage	DCI-P3	41% coverage
	Rec.2020	29% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

Kyocera KCB104VG2BA-A21 Electronics Details

Frame Frequency :	75Hz
Reverse Scan :	No
Driving Method :	Duty: 1/240

Kyocera KCB104VG2BA-A21 Backlight Details

Back-light Features:	Lamp Shape	Straight	Lamp Type	CCFL	Life Time	60K(Typ.) (Hours)
Back-light Features:	Replacement	-	Amount	2 pcs	Position	Edge light type (Top and Bottom)
Lamp Electrical :	Voltage Input	540V (Typ.)		Current Input	2.0/5.0/6.0mA (Min./Typ./Max.)
Lamp Electrical :	Frequency	40/100KHz (Min./Max.)		Kick-off Voltage	905/1360V Max.)(Ta=+25/0℃)
Interface Features :	Type	Connector	Position	-	Lamp Driver	Optional
Interface Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Interface Detail :	HONDA	QZ-19-3F01		3 pins	2 pcs	BLL-3PINS-LNH

Kyocera KCB104VG2BA-A21 Interface Details

Signal Systerm :	Parallel Data (8-bit)			Logic Voltage	-
Signal Electrical :	Voltage Input	5.0V (Typ.)		Current Input	68/102mA (Typ./Max.)
Signal Electrical :	Consumption	340/510mW (Typ./Max.)
Interface Features :	Type	Connector	Position	-
Connector Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
	molex	53261-1510	1.25 mm	15 pins	1 pcs	PD-29P1C8B-010A
	molex	53261-1410	1.25 mm	14 pins	1 pcs

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.

KCB104VG2BA-A21 Kyocera 10.4INCH LCM 640×480RGB 150NITS CCFL INDUSTRIAL LCD DISPLAY

Product Tags:

WLED FSTN LCD display

WLED Industrial TFT Display

KCB104VG2BA-A21 Kyocera 10.4INCH LCM 640×480RGB 150NITS CCFL INDUSTRIAL LCD DISPLAY Images
