TCG075VGLBA-G20 Kyocera 7.5INCH LCM 640×480RGB 250NITS WLED TTL INDUSTRIAL LCD DISPLAY

Product Categories
Sapientia Display Co.,LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

TCG075VGLBA-G20 Kyocera 7.5INCH LCM 640×480RGB 250NITS WLED TTL INDUSTRIAL LCD DISPLAY

  • 1
  • 2
  • 3

Brand Name : Kyocera

Model Number : TCG075VGLBA-G20

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW

Supply Ability : 50PCS

Delivery Time : 1-2day

Packaging Details : STANDARD PACKING

BRAND : Kyocera

MODEL NUMBER : TCG075VGLBA-G20

SIZE : 7.5INCH

RESOLUTION : 640×480RGB

BRIGHTNESS : 250 cd/m² (Typ.)

Interface Type : Parallel RGB (1 ch, 6-bit) , 40 pins Connector

Light Source : WLED , 40K hours , With LED Driver

TEMPERATURE RANGE : Operating Temperature: -20 ~ 70 °C

Contact Now

Kyocera TCG075VGLBA-G20 Application Details

Basic Information :
Brand

TCG075VGLBA-G20Model
Type
a-Si TFT-LCD , LCM
Used For

7.5 inchScreen Size
Alias
-
Environment :
Storage Temp.
-30 ~ 80 °C
Operating Temp.
-20 ~ 70 °C
RoHS

-Vibration



Kyocera TCG075VGLBA-G20 Mechanical Details

Pixel Features :
Resolution
640(RGB)×480, VGA
Dot Pitch(mm)
0.079×0.237 (H×V)
Pixel Format
RGB Vertical Stripe
Pixel Pitch(mm)
0.237×0.237 (H×V) [107PPI]
Mechanical Size :
Active Area(mm)
151.68(H) × 113.76(V)
Bezel Area(mm)
156.3(H) × 118.4(V)
Outline Dim.(mm)
173(H) × 133(V)
Depth(mm)
6.35 (Typ.)
Outline Features :
Form Style
Flat Rectangle
Shape Style

Aspect Ratio
4:3 (H:V)
Orientation
Landscape type
Other Spec :
Weight
220g (Typ.)
Treatment
Glare (Haze 0%)



Kyocera TCG075VGLBA-G20 Optical Details

Basic Information :
Luminance(cd/m²)
250 (Typ.)
Contrast Ratio
450:1 (Typ.) (Transmissive)
Viewing Angle
70/70/50/70 (Typ.)(CR≥5)
Display Mode
TN, Normally White, Transmissive
Best View on
-
Response(ms)
5/15 (Typ.)(Tr/Td)
Color Performance :
White Coordinate
Wx:0.320; Wy:0.340
Display Colors
262K (6-bit)
Color Temperature
6066K
White Uniformity
-
1931 Color Gamlt :
NTSC Ratio
52%
sRGB
71% coverage
Adobe RGB
55% coverage
DCI-P3
54% coverage
Rec.2020
39% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



Kyocera TCG075VGLBA-G20 Electronics Details

Reverse Scan :
Yes (U/D, L/R)





Kyocera TCG075VGLBA-G20 Interface Detail

Signal Electrical :
Voltage Supply
3.3V (Typ.)
Current Supply
300/390mA (Typ./Max.)
Signal Type :
Parallel RGB (1 ch, 6-bit)
Logic Voltage
-
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Quantity
Pin Configuration
IRISO
IMSA-9681S-40A-GF
0.5 mm
40 pins
1 pcs



Kyocera TCG075VGLBA-G20 Backlight Details

Backlight Features :
Type
WLED
Quantity
-
Position
Edge light type
Replacement
-
Shape
-
Life Time
40K(Typ.) (Hours)
Interface Features :
Position
-
Type
Included in panel signal interface
Backlight Driver :
With LED Driver
Driver Electrical :
Voltage Supply
3.0/5.5V (Min./Max.)
Current Supply
-



FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.





TCG075VGLBA-G20 Kyocera 7.5INCH LCM 640×480RGB 250NITS WLED TTL INDUSTRIAL LCD DISPLAYTCG075VGLBA-G20 Kyocera 7.5INCH LCM 640×480RGB 250NITS WLED TTL INDUSTRIAL LCD DISPLAY






Product Tags:

WLED Industrial TFT Display



WVGA Industrial Lcd Panel


Buy cheap TCG075VGLBA-G20 Kyocera 7.5INCH LCM 640×480RGB 250NITS WLED TTL INDUSTRIAL LCD DISPLAY product

TCG075VGLBA-G20 Kyocera 7.5INCH LCM 640×480RGB 250NITS WLED TTL INDUSTRIAL LCD DISPLAY Images
