TCG075VGLAE-G00 Kyocera 7.5INCH LCM 640×480RGB 280NITS WLED TTL INDUSTRIAL LCD DISPLAY

Product Categories
Sapientia Display Co.,LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

TCG075VGLAE-G00 Kyocera 7.5INCH LCM 640×480RGB 280NITS WLED TTL INDUSTRIAL LCD DISPLAY

  • 1
  • 2
  • 3

Brand Name : Kyocera

Model Number : TCG075VGLAE-G00

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW

Supply Ability : 50PCS

Delivery Time : 1-2day

Packaging Details : STANDARD PACKING

BRAND : Kyocera

MODEL NUMBER : TCG075VGLAE-G00

SIZE : 7.5INCH

RESOLUTION : 640×480RGB

BRIGHTNESS : 280 cd/m² (Typ.)

Backlight : 4 strings WLED , 50K hours , No Driver

Screen Type : LCM , a-Si TFT-LCD

TEMPERATURE RANGE : Storage Temp.: -30 ~ 80 °C

Contact Now

Kyocera TCG075VGLAE-G00 Application Details

Basic Detail : Manufacturer   Model Name TCG075VGLAE-G00
Panel Type a-Si TFT-LCD , LCM Another Name -
Panel Size 7.5 inch Designed For
Maximum Ratings : OP Temperature -10 ~ 70 °C ST Temperature -30 ~ 80 °C
Vibration Level - RoHS



Kyocera TCG075VGLAE-G00 Optical Details

Basic Information : Luminance 280 cd/m² (Typ.) Contrast Ratio 450 : 1 (Typ.) (Transmissive)
Good View at - Response Speed 5/15 (Typ.)(Tr/Td) (ms)
Viewing Angle 70/70/50/70 (Typ.)(CR≥5)  Operating Mode TN, Normally White, Transmissive
Color Performance : Chromaticity Wx:0.330; Wy:0.350 Support Color 262K (6-bit)
Color Temperature 5598K White Uniformity -
1931 Color Gamlt : NTSC Ratio 47% sRGB 65% coverage
Adobe RGB 49% coverage DCI-P3 48% coverage
Rec.2020 35% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



Kyocera TCG075VGLAE-G00 Mechanical Details

Pixel Features : Number of Pixel 640(RGB)×480 [VGA] Arrangement RGB Vertical Stripe
Dot Pitch(W×H) 0.079×0.237 mm Pixel Pitch(W×H) 0.237×0.237 mm [107PPI]
Physical Size : Active Viewing 151.68(W)×113.76(H) mm Overall Dim. 184(W)×139.8(H) mm
Bezel Opening 153.7(W)×115.8(H) mm Overall Depth 12.7 mm
Outline Features : Form Shape Flat Rectangle Orientation Landscape type
Aspect Ratio(W:H) 4:3 Shape Style
Fixation : Rear mounting holes
Other Detail : Mass 370g Surface Glare (Haze 0%)



Kyocera TCG075VGLAE-G00 Electronics Details

Refresh Rate : 60Hz
Reverse Scan : Yes (U/D, L/R)
Time Controller (T-CON) : Embedded T-CON



Kyocera TCG075VGLAE-G00 Interface Details

Signal Electrical : Input Current 290/435mA (Typ./Max.) Input Voltage 3.3V (Typ.)
Consumption - Signal Interface Parallel RGB (1 ch, 6-bit)
Logic Voltage for Signals : 0≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD
Interface Features : Position - Physical Type Connector
Signal Interface : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
Kyocera Elco 08-6210-033-340-800+ 1 pcs 0.5 mm 33 pins DRGB-33P1C6B-020C



Kyocera TCG075VGLAE-G00 Lightting Details

Lamp Features: Lamp Shape 4 strings Lamp Type WLED Position Edge light type
Exchange - Amount 4 strings Life 50K(Typ.) (Hours)
Lamp Electrical : Input Current 25mA (Typ.) Input Voltage 23.1/25.9V (Typ./Max.)
Interface Features : Position - Physical Type Connector
Interface Detail : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
JST SHLP-08V-S-B 1 pcs 1.0 mm 8 pins BLE-8PINS-AAAACCCC
Backlight Driver : No



FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
