TCG057QVLCS-H50 Kyocera 5.7INCH LCM 320×240RGB 1000NITS WLED TTL INDUSTRIAL LCD DISPLAY

Product Categories
Sapientia Display Co.,LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

TCG057QVLCS-H50 Kyocera 5.7INCH LCM 320×240RGB 1000NITS WLED TTL INDUSTRIAL LCD DISPLAY

  • 1
  • 2
  • 3

Brand Name : Kyocera

Model Number : TCG057QVLCS-H50

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW

Supply Ability : 200PCS

Delivery Time : 1-2day

Packaging Details : STANDARD PACKING

MODEL NUMBER : TCG057QVLCS-H50

BRAND : Kyocera

SIZE : 5.7INCH

RESOLUTION : 320×240RGB

BRIGHTNESS : 1000 cd/m² (Typ.)

Interface Type : Parallel RGB (1 ch, 6-bit) 33 pins Connector

Light Source : WLED [2 strings] , 50K hours , W/O Driver

TEMPERATURE RANGE : Storage Temp.: -30 ~ 80 °C

Contact Now

Kyocera TCG057QVLCS-H50 Application Details

Basic Info : Panel Brand   Panel Model TCG057QVLCS-H50
Diagonal Size 5.7" Application




  •
Panel Type a-Si TFT-LCD , LCM Model Alias -
Reliability : Operating Temp. -20 ~ 70 °C Storage Temp. -30 ~ 80 °C
RoHS State   Vibration Rating -



Kyocera TCG057QVLCS-H50 Mechanical Details

Pixel Features : Pixel Format 320(RGB)×240 [QVGA] Dot Pitch 0.120×0.360 mm (H×V)
Configuration RGB Vertical Stripe Pixel Pitch 0.360×0.360 mm (H×V) [70PPI]
Mechanical Size : Display Area 115.2×86.4 mm (H×V) Bezel Area 118.4×89.6 mm (H×V)
Outline Dim. 144×104.8 mm (H×V) Outline Depth 13.0±0.5 mm
Outline Features : Form Factor Flat Rectangle Orientation Landscape type
Aspect Ratio 4:3 (H:V) Shape Style
Holes & Brackets : Rear mounting holes (4-Φ2.6)
Other Features : Weight 210g (Typ.) Surface Glare (Haze 0%), Antireflection



Kyocera TCG057QVLCS-H50 Optical Details

Basic Information : Brightness 1000 cd/m² (Typ.) Contrast Ratio 500:1 (Typ.) (Transmissive)
Viewing Angle 80/80/80/80 (Typ.)(CR≥5) Optical Mode TN, Normally White, Transmissive
Viewing Direction - Response Time 10/25 (Typ.)(Tr/Td) (ms)
Color Performance : Chromaticity Wx:0.320; Wy:0.340 Color Numbers 262K (6-bit)
Color Temperature 6066K White Uniformity -
1931 Color Gamlt : NTSC Ratio 59% sRGB 77% coverage
Adobe RGB 61% coverage DCI-P3 61% coverage
Rec.2020 44% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance : Outdoor Visibility Sunlight Readable Transmittance -



Kyocera TCG057QVLCS-H50 Electronics Details

Reverse Scan : Yes (U/D, L/R)



Kyocera TCG057QVLCS-H50 Backlight Details

Back-light Features: Lamp Shape 2 strings Lamp Type WLED Life Time 50K(Typ.) (Hours)
Replacement - Amount 2 strings Position Edge light type
Lamp Electrical : Voltage Input 18.0/21.2V (Typ./Max.) Current Input 60mA (Typ.)
Interface Features : Type Connector Position - Lamp Driver No
Interface Detail : Brand Model Pin Pitch Pins Amount Configuration
JST PHR-4 2.0 mm 4 pins 1 pcs BLE-4PINS-AACC



Kyocera TCG057QVLCS-H50 Interface Details

Signal Systerm : Parallel RGB (1 ch, 6-bit) Logic Voltage 0≤VIL≤0.3VDD; 0.7VDD≤VIH≤5.5V
Signal Electrical : Voltage Input 3.3V (Typ.) Current Input 60/80mA (Typ./Max.)
Interface Features : Type Connector Position -
Connector Detail : Brand Model Pin Pitch Pins Amount Configuration
IRISO IMSA-9632S-33Z02-GF1 0.5 mm 33 pins 1 pcs DRGB-33P1C6B-020A
