TG035QVLQAANN-GN00 Kyocera 3.5INCH LCM 320×240RGB 1200NITS WLED TTL INDUSTRIAL LCD DISPLAY

Name: TG035QVLQAANNGN00 Kyocera 35INCH LCM 320240RGB 1200NITS WLED TTL INDUSTRIAL LCD DISPLAY
Brand: Kyocera
Price: 1 USD

Buy cheap TG035QVLQAANN-GN00 Kyocera 3.5INCH LCM 320×240RGB 1200NITS WLED TTL INDUSTRIAL LCD DISPLAY product

Brand Name : Kyocera

Model Number : TG035QVLQAANN-GN00

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW

Supply Ability : 50PCS

Delivery Time : 1-2day

Packaging Details : STANDARD PACKING

BRAND : Kyocera

MODEL NUMBER : TG035QVLQAANN-GN00

SIZE : 3.5INCH

RESOLUTION : 320×240RGB

BRIGHTNESS : 1200 cd/m² (Typ.)

Signal Type : Parallel RGB (1 ch, 8-bit) + SPI , 50 pins FPC

Backlight : WLED , 60K hours , No Driver

Max. Ratings : Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C

Contact Now

Kyocera TG035QVLQAANN-GN00 Application Details

Basic Information :	Brand		Model	TG035QVLQAANN-GN00
	Type	LCM a-Si TFT-LCD	Used For
	Screen Size	3.5"	Alias	-
Environment :	Storage Temp.	-30 ~~ 80 °C	Operating Temp.	-20 ~~ 70 °C
Environment :	RoHS		Vibration	-

Kyocera TG035QVLQAANN-GN00 Mechanical Details

Pixel Features :	Resolution	320(LCR)×240, QVGA	Dot Pitch(mm)	0.0735×0.2205 (H×V)
Pixel Features :	Pixel Format	LCR Vertical Stripe	Pixel Pitch(mm)	0.2205×0.2205 (H×V) [115PPI]
Mechanical Size :	Active Area(mm)	70.56(H) × 52.92(V)	Bezel Area(mm)	72.26(H) × 54.62(V)
Mechanical Size :	Outline Dim.(mm)	76.9(H) × 63.9(V)	Depth(mm)	4.90±0.3
Outline Features :	Form Style	Flat Rectangle	Outline Shape
Outline Features :	Aspect Ratio	4:3 (H:V)	Orientation	Landscape type
Other Spec :	Weight	40.0g	Treatment	-

Kyocera TG035QVLQAANN-GN00 Optical Details

Basic Information :	Luminance(cd/m²)	1200 (Typ.)	Contrast Ratio	1000:1 (Typ.) (Transmissive)
	Viewing Angle	80/80/80/60 (Typ.)(CR≥10)	Display Mode	TN, Normally White, Transmissive
	Best View on	12 o'clock	Response(ms)	8/22 (Typ.)(Tr/Td)
Color Performance :	White Coordinate	X:0.310; Y:0.310	Display Colors	Grayscale (6-bit)
Color Performance :	Color Temperature	6852K	White Uniformity	-
Dispaly Performance :	Outdoor Visibility	Sunlight Readable	Transmissivity	-

Kyocera TG035QVLQAANN-GN00 Electronics Details

Frame Rate :	60Hz
Reverse Scan :	Yes (180°)

Kyocera TG035QVLQAANN-GN00 Interface Details

Signal Electrical :	Voltage Supply	3.3V (Typ.)		Current Supply	8.0/11.3mA (Typ./Max.)
Signal Type :	Parallel RGB (1 ch, 8-bit) + SPI			Signal Voltage	0≤VIL≤0.3VDD; 0.8VDD≤VIH≤VDD
Interface Features :	Position	-		Type	FPC
Interface Detail :	Brand	Model	Quantity	Pins	Pitch	Pin Configuration
Interface Detail :			1 pcs	50 pins	0.5 mm

Kyocera TG035QVLQAANN-GN00 Backlight Details

Backlight Features:	Shape	2 strings	Type	WLED	Position	Edge light type
Backlight Features:	Replacement	-	Quantity	-	Life Time	60K(Typ.) (Hours)
Lamp Electrical :	Voltage Supply	12.5/13.3V (Typ./Max.)		Current Supply	15mA (Typ.)
Interface Features :	Position	-		Type	Included in panel signal interface
Backlight Driver :	No

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
