LM240WU4-SLB1 LG Display 24.0" 1920(RGB)×1200 400 cd/m² INDUSTRIAL LCD DISPLAY

Name: LM240WU4SLB1 LG Display 240quot 1920RGB1200 400 cdm INDUSTRIAL LCD DISPLAY
Brand: LG Display
Price: 1 USD

Buy cheap LM240WU4-SLB1 LG Display 24.0" 1920(RGB)×1200 400 cd/m² INDUSTRIAL LCD DISPLAY product

Brand Name : LG Display

Model Number : LM240WU4-SLB1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 100PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LM240WU4-SLB1

BRAND : LG Display

SIZE : 24.0 inch

BRIGHTNESS : 400CD/M2

Lamp Type : WLED

RESOLUTION : 1920(RGB)×1200 (WUXGA) 94PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C

Contact Now

LG Display LM240WU4-SLB1 Application Details

Basic Information :	Brand		Model	LM240WU4-SLB1
	Type	LCM a-Si TFT-LCD	Used For
	Screen Size	24.0"	Alias	LM240WU4 (SL)(B1)
Environment :	Storage Temp.	-20 ~~ 60 °C	Operating Temp.	0 ~~ 50 °C

LG Display LM240WU4-SLB1 Mechanical Details

Pixel Features :	Resolution	1920(RGB)×1200, WUXGA	Dot Pitch(mm)	0.090×0.270 (H×V)
Pixel Features :	Pixel Format	RGB Vertical Stripe	Pixel Pitch(mm)	0.270×0.270 (H×V) [94PPI]
Mechanical Size :	Active Area(mm)	518.4(H) × 324(V)	Bezel Area(mm)	522.4(H) × 328.0(V)
Mechanical Size :	Outline Dim.(mm)	546.4(H) × 352(V)	Depth(mm)	28.8/40.8 (Typ./Max.)
Outline Features :	Form Style	Flat Rectangle	Outline Shape	Normal bezel
Outline Features :	Aspect Ratio	16:10 (H:V)	Orientation	Landscape type
Mounting :	Side mounting holes (9 pcs) on left, right, up, down bezel
Other Spec :	Weight	2.74/2.88Kgs (Typ./Max.)	Treatment	Antiglare, Hard coating (3H)

LG Display LM240WU4-SLB1 Optical Details

Basic Information :	Luminance(cd/m²)	400 (Typ.)	Contrast Ratio	1000:1 (Typ.) (Transmissive)
	Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Display Mode	S-IPS, Normally Black, Transmissive
	Best View on	Symmetry	Response(ms)	6/7 (Typ.)(Tr/Td); 6 (Typ.)(G to G)
Color Performance :	White Coordinate	X:0.313; Y:0.329	Display Colors	1.07B (8-bit + Hi-FRC)
Color Performance :	Color Temperature	6485K	White Uniformity	1.33 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio	102%	sRGB	100% coverage
	Adobe RGB	98% coverage	DCI-P3	92% coverage
	Rec.2020	76% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LM240WU4-SLB1 Interface Details

Signal Electrical :	Voltage Supply	12.0V (Typ.)		Current Supply	462/531mA (Typ./Max.)
Signal Electrical :	Consumption	5.54/6.38W (Typ./Max.)
Signal Type :	LVDS (2 ch, 10-bit)			Signal Voltage	-
Interface Features :	Position	-		Type	Connector
Interface Detail :	Brand	Model	Quantity	Pins	Pitch	Pin Configuration
Interface Detail :	JAE	FI-RE51S-HF	1 pcs	51 pins	0.5 mm	LVDS-51P2C10B-050A

LG Display LM240WU4-SLB1 Backlight Details

Backlight Features:	Shape	U shape	Type	CCFL	Position	Direct light type
Backlight Features:	Replacement	-	Quantity	7 pcs	Life Time	40K(Min.) (Hours)
Interface Features :	Position	-		Type	Connector
Interface Detail :	Brand	Model	Quantity	Pins	Pitch	Pin Configuration
Interface Detail :	JST	S14B-PHA-SM3-TB	1 pcs	14 pins	2.0 mm
Backlight Driver :	With Inverter
Driver Electrical :	Voltage Supply	24.0V (Typ.)		Current Supply	3.0/3.5A (Typ./Max.)
Driver Electrical :	Consumption	72.0/84.0W (Typ./Max.)

LG Display LM240WU4-SLB1 Packing Details

Package Box :	Quantity	Weight	Box Size
Package Box :	5 pcs / box	-	436×346×618 mm (L×W×H)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
