99PPI 20.1" 1600x1200 Tft Lcd Screen 300cd/m2 LM201U04-SL02 89/89/89/89 (Typ.)(CR≥10)

Name: 99PPI 201quot 1600x1200 Tft Lcd Screen 300cdm2 LM201U04SL02 89898989 TypCR10
Brand: LG. LCD
Price: 1 USD

Buy cheap 99PPI 20.1" 1600x1200 Tft Lcd Screen 300cd/m2 LM201U04-SL02 89/89/89/89 (Typ.)(CR≥10) product

Brand Name : LG. LCD

Model Number : LM201U04-SL02

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 120PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LM201U04-SL02

BRAND : LG. LCD

SIZE : 20.1INCH

BRIGHTNESS : 300CD/M2

Lamp Type : WLED

RESOLUTION : 1600(RGB)×1200, UXGA, 99PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG. LCD LM201U04-SL02 Application Details

Basic Info :	Panel Brand		Panel Model	LM201U04-SL02
	Diagonal Size	20.1"	Application
	Panel Type	a-Si TFT-LCD , LCM	Model Alias	LM201U04 (SL)(02)
Reliability :	Operating Temp.	0 ~ 50 °C	Storage Temp.	-20 ~ 60 °C
Reliability :	RoHS State		Vibration Rating	-

LG. LCD LM201U04-SL02 Mechanical Details

Pixel Features :	Pixel Format	1600(RGB)×1200 [UXGA]	Dot Pitch	0.085×0.255 mm (H×V)
Pixel Features :	Configuration	RGB Vertical Stripe	Pixel Pitch	0.255×0.255 mm (H×V) [99PPI]
Mechanical Size :	Display Area	408×306 mm (H×V)	Bezel Area	413.0×311.0 mm (H×V)
Mechanical Size :	Outline Dim.	432×331.5 mm (H×V)	Outline Depth	17.4/25.5 (Typ./Max.) mm
Outline Features :	Form Factor	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio	4:3 (H:V)	Shape Style	Normal bezel
Holes & Brackets :	Side mounting holes (4-M3) on left, right bezel
Other Features :	Weight	3.20Kgs (Typ.)	Surface	Antiglare (Haze 25%), Hard coating (3H)

LG. LCD LM201U04-SL02 Optical Details

Basic Information :	Brightness	300 cd/m² (Typ.)	Contrast Ratio	700:1 (Typ.) (Transmissive)
	Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Optical Mode	S-IPS, Normally Black, Transmissive
	Viewing Direction	Symmetry	Response Time	7/9 (Typ.)(Tr/Td); 12 (Typ.)(G to G) (ms)
Color Performance :	Chromaticity	Wx:0.313; Wy:0.329	Color Numbers	16.7M (8-bit)
Color Performance :	Color Temperature	6485K	White Uniformity	1.39 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio	72%	sRGB	94% coverage
	Adobe RGB	75% coverage	DCI-P3	75% coverage
	Rec.2020	54% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG. LCD LM201U04-SL02 Backlight Details

Back-light Features:	Lamp Shape	Straight	Lamp Type	CCFL	Life Time	45K(Min.) (Hours)
Back-light Features:	Replacement	-	Amount	6 pcs	Position	Edge light type (Top and Bottom)
Lamp Electrical :	Voltage Input	680/700/825V (Min./Typ./Max.)		Current Input	3.0/7.0/7.5mA (Min./Typ./Max.)
	Frequency	40/50/80KHz (Min./Typ./Max.)		Kick-off Voltage	1150/1450V (Max.)(Ta=+25/0℃)
	Consumption	29.4/32.3W (Typ./Max.)
Interface Features :	Type	Connector	Position	-	Lamp Driver	No
Interface Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
	JST	BHSR-02VS-1	3.5 mm	2 pins	2 pcs	BLL-2PINS-HL
	JST	BHR-05VS-1	4.0 mm	5 pins	2 pcs	BLL-5PINS-HHNLL

LG. LCD LM201U04-SL02 Interface Details

Signal Systerm :	LVDS (2 ch, 8-bit)			Logic Voltage	-
Signal Electrical :	Voltage Input	20.0V (Typ.)		Current Input	280/360mA (Typ./Max.)
Signal Electrical :	Consumption	5.58/7.2W (Typ./Max.)
Interface Features :	Type	Connector	Position	-
Connector Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Connector Detail :	JAE	FI-XB30SRL-HF11	1.0 mm	30 pins	1 pcs	LVDS-30P2C8B-030A

LG. LCD LM201U04-SL02 Carton Details

Package Carton :	Amount	Net Weight	Carton Size (L×W×H)
Package Carton :	5 pcs / box	-	530×307×453 mm
