15.0" 1024x768 150cd/m2 Tft Lcd Screen 85PPI LP150X08-TLA8 45/45/15/35 (Typ.)(CR≥10)

Name: 150quot 1024x768 150cdm2 Tft Lcd Screen 85PPI LP150X08TLA8 45451535 TypCR10
Brand: LG. LCD
Price: 1 USD

Buy cheap 15.0" 1024x768 150cd/m2 Tft Lcd Screen 85PPI LP150X08-TLA8 45/45/15/35 (Typ.)(CR≥10) product

Brand Name : LG. LCD

Model Number : LP150X08-TLA8

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 120PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LP150X08-TLA8

BRAND : LG.LCD

SIZE : 15.0 inch

BRIGHTNESS : 150CD/M2

Lamp Type : WLED

RESOLUTION : 1024(RGB)×768, XGA, 85PPI

VIEWING ANGLEG : 45/45/15/35 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

G. LCD LP150X08-TLA8 Application Details

Basic Info :	Panel Brand LP150X08-TLA8Panel Model Diagonal Size 15.0" Application a-Si TFT-LCD , LCMPanel Type Model Alias LP150X08 (TL)(A8), LEN4040
Reliability :	Operating Temp. 0 ~ 50 °C Storage Temp. -20 ~ 60 °C RoHS State 1.5G (14.7 m/s²)Vibration Rating

LG.LCD LP150X08-TLA8 Mechanical Details

Pixel Features :	Pixel Format 1024(RGB)×768, XGA Dot Pitch 0.099×0.297 mm (H×V) Configuration RGB Vertical Stripe Pixel Pitch 0.297×0.297 mm (H×V) [85PPI]
Mechanical Size :	Display Area 304.128×228.096 mm (H×V) Bezel Area 307.5×231.4 mm (H×V) Outline Dim. 317.3×241.5 mm (H×V) Outline Depth 5.9±0.3 mm
Outline Features :	Form Factor Flat Rectangle Orientation Landscape type Aspect Ratio 4:3 (H:V) Shape Style Wedge (PCBA Bent, T≥5.2mm)
Holes & Brackets :	Side mounting holes (8-M2) on left, right bezel
Other Features :	Weight 530/545g (Typ./Max.) Surface Antiglare, Hard coating (3H)

LG. LCD LP150X08-TLA8 Optical Details

Basic Information :	Brightness 150 cd/m² (Typ.) Contrast Ratio 250:1 (Typ.) (Transmissive) Viewing Angle 45/45/15/35 (Typ.)(CR≥10) Optical Mode TN, Normally White, Transmissive Viewing Direction 6 o'clock Response Time 10/20 (Typ.)(Tr/Td) ms
Color Performance :	Chromaticity Wx:0.313; Wy:0.329 Color Numbers 262K (6-bit) Color Temperature 6485K Uniformity 1.67 (Max.)(13 points)
1931 Color Gamlt :	NTSC Ratio 43% sRGB 60% coverage Adobe RGB 45% coverage DCI-P3 45% coverage Rec.2020 32% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG. LCD LP150X08-TLA8 Backlight Details

Back-light Features :	Lamp Type CCFL Amount 1 pcs Life Time 12K(Min.) (Hours) Replacement - Lamp Shape Straight Position Edge light type (Bottom side)
Lamp Electrical :	Voltage Input 658/675/815V (Min./Typ./Max.) Current Input 3.0/6.0/6.5mA (Min./Typ./Max.) Frequency 50/65/80KHz (Min./Typ./Max.) Kick-off Voltage 1165/1400V (Max.)(Ta=+25/0℃) Consumption 3.9/4.3W (Typ./Max.)
Interface Features :	Type Connector Position - Lamp Driver No
Interface Detail :	Brand Model Pin Pitch Pins Amount Configuration JST BHSR-02VS-1 3.5 mm 2 pins 1 pcs BLL-2PINS-HL

LG. LCD LP150X08-TLA8 Interface Detail

Signal Systerm :	LVDS (1 ch, 6-bit) Logic Voltage -
Signal Electrical :	Voltage Input 3.3V (Typ.) Current Input 230/265mA (Typ./Max.) Consumption 0.76/0.87W (Typ./Max.)
Interface Features :	Type Connector Position -
Connector Detail :	Brand Model Pin Pitch Pins Amount Configuration LS Mtron GT101-30S-HR11 1.0 mm 30 pins 1 pcs LVDS-30P1C6B-060B

LG. LCD LP150X08-TLA8 Carton Details

Package Carton :	Amount	Net Weight	Carton Size (L×W×H)
Package Carton :	20 pcs / box	-	388×334×318 mm
