80PPI 400cd/m2 High Brightness Lcd Screen 400CD/M2 55" LC550EQG-FLM1

Name: 80PPI 400cdm2 High Brightness Lcd Screen 400CDM2 55quot LC550EQGFLM1
Brand: LG Display
Price: 1 USD

Buy cheap 80PPI 400cd/m2 High Brightness Lcd Screen 400CD/M2 55" LC550EQG-FLM1 product

Brand Name : LG Display

Model Number : LC550EQG-FLM1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 120PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LC550EQG-FLM1

BRAND : LG Display

SIZE : 55 inch

BRIGHTNESS : 400CD/M2

Lamp Type : WLED

RESOLUTION : 3840(RGB)×2160, UHD, 80PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG Display LC550EQG-FLM1 Application Features

Basic Information :	Manufacturer	Panel Model	Panel Type	Alias
Basic Information :		LC550EQG-FLM1	a-Si TFT-LCD , LCM	LC550EQG (FL)(M1)
Environment :	RoHS State	Operating Temp.	Storage Temp.	Vibration Level
Environment :		0 ~ 50 °C	-20 ~ 60 °C

LG Display LC550EQG-FLM1 Optical Features

Basic Information :	Luminance (cd/m²)	Viewing Angle (L/R/U/D)	Response Time (ms)
	400 (Typ.)	89/89/89/89 (Min.)(CR≥10)	8/10 (Typ.)(Tr/Td)
	Best View on	Display Mode	Contrast Ratio
	Symmetry	IPS, Normally Black, Transmissive	1400 : 1 (Typ.) (Transmissive)
Dispaly Color :	Color Temperature	Display Colors	White Coordinate
Dispaly Color :	9966K	1.07B (10-bit)	X:0.281; Y:0.288
1931 Color Gamlt :	NTSC Ratio	sRGB Coverage	Adobe RGB Coverage
	84%	99%	78%
	DCI-P3 Coverage	Rec.2020 Coverage	Remarks
	85%	62%	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
White Variation :	1.54 (Max.)(9 points)

LG Display LC550EQG-FLM1 Mechanical Features

Panel Size :	55"
Pixel Features :	Pixel Format	Pixel Configuration	Pixel Pitch (mm)	Dot Pitch (mm)
Pixel Features :	3840(RGB)×2160 [UHD]	RGB Vertical Stripe	0.315×0.315 [80PPI]	0.105×0.315
Mechanical Size :	Active Area (mm)	Bezel Area (mm)	Outline Dimension (mm)	Outline Depth (mm)
Mechanical Size :	1209.6(H) × 680.4(V)	1215.6(H) × 685.9(V)	1235.4(H) × 715.4(V)	24.8 (Typ.) mm
Outline Features :	Form Factor	Orientation	Aspect Ratio	Shape Style
Outline Features :	Flat Rectangle	Landscape type	16:9 (H:V)
Mounting :	Rear mounting holes
Other Detail :	Weight	Panel Cover	Treatment
Other Detail :	12.0Kgs (Typ.)	-	Antiglare (Haze 3%), Hard coating (2H)

LG Display LC550EQG-FLM1 Backlight Features

Lamp Features:	Type	Position	Quantity	Shape	Life(Hours)	Lamp Exchange
Lamp Features:	WLED	Edge light type	-	-	30K(Min.)	-
WLED Electrical :	Voltage Supply		Current Supply			Power
WLED Electrical :	128.7±7.7V		110±5.5mA			84.9/90W (Typ./Max.)
Interface Features :	Position	Backlight Driver				Type
Interface Features :	-	No				Connector
Interface Detail :	Brand	Model	Pin Pitch	Pin Amount	Quantity	Configuration
	UJU	HS100-L08N-N62	1.0 mm	8 pins	1 pcs
	UJU	HS100-L08N-N62-A	1.0 mm	8 pins	1 pcs

LG Display LC550EQG-FLM1 Interface Features

Panel Driving Electrical :	Voltage Supply		Current Supply			Power
Panel Driving Electrical :	12.7V (Typ.)		0.96/1.25A (Typ./Max.)			12.19/15.84W (Typ./Max.)
Interface Features :	Position	Signal				Type
Interface Features :	-	EPI				Connector
Connector Detail :	Brand	Model	Pin Pitch	Pin Amount	Quantity	Configuration
Connector Detail :	HRS	TF06L-60S-0.5SH	0.5 mm	60 pins	2 pcs

LG Display LC550EQG-FLM1 Packing Features

Package Box :	Quantity	Weight	Box Size
Package Box :	18 pcs / box	-	1440×1140×960 mm (L×W×H)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
