46PPI 700cd/M2 Square LCD Panel 47.0" 1920×1080 LD470EUP-SEA1 89/89/89/89 (Typ.)(CR≥10)

Name: 46PPI 700cdM2 Square LCD Panel 470quot 19201080 LD470EUPSEA1 89898989 TypCR10
Brand: LG Display
Price: 1 USD

Buy cheap 46PPI 700cd/M2 Square LCD Panel 47.0" 1920×1080 LD470EUP-SEA1 89/89/89/89 (Typ.)(CR≥10) product

Brand Name : LG Display

Model Number : LD470EUP-SEA1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 200PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LD470EUP-SEA1

BRAND : LG Display

SIZE : 27.0"inch

BRIGHTNESS : 700CD/M2

Lamp Type : WLED

RESOLUTION : 1920(RGB)×1080 [FHD] 46PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG Display LD470EUP-SEA1 Application Features

Basic Information :	Brand	Model	Type	Model Alias
Basic Information :		LD470EUP-SEA1	a-Si TFT-LCD , LCM	LD470EUP (SE)(A1)
Reliability :	RoHS	Operating Temperature	Storage Temperature	Vibration Resistance
Reliability :		0 ~ 50 °C	-20 ~ 60 °C

LG Display LD470EUP-SEA1 Mechanical Features

Panel Size :	47 inch
Pixel Features :	Resolution	Pixel Arrangement	Dot Pitch (W×H)	Pixel Pitch (W×H)
Pixel Features :	1920(RGB)×1080, FHD	RGB Vertical Stripe	0.1805×0.5415 mm	0.5415×0.5415 mm [46PPI]
Mechanical Size :	Active Area (W×H)	Bezel Area (W×H)	Outline Dimension (W×H)	Outline Depth
Mechanical Size :	1039.68×584.82 mm	1048.8×593.0 mm	1068.8×612.8 mm	20.8/30.5 (Typ.) mm
Outline Features :	Form Style	Aspect Ratio	Orientation	Shape Style
Outline Features :	Flat Rectangle	16:9 (W : H)	Landscape / Portrait
Other Features :	Panel Cover	Weight	Surface
Other Features :	-	10.9/11.5Kgs (Typ./Max.)	Antiglare (Haze 10%), Hard coating (3H)

LG Display LD470EUP-SEA1 Optical Features

Basic Information :	Brightness	Operating Mode	Contrast Ratio
	700 cd/m² (Typ.)	S-IPS, Normally Black, Transmissive	1500:1 (Typ.) (Transmissive)
	Viewing Angle(L/R/U/D)	Viewing Direction	Response Speed
	89/89/89/89 (Min.)(CR≥10)	Symmetry	12 (Typ.)(G to G) (ms)
Dispaly Color :	Color Temperature	Color Amount	White color Chromaticity
Dispaly Color :	9972K	16.7M/1.06B (8-bit / 8-bit + Dithering)	X:0.279; Y:0.292
Luminance Variation :	1.30 (Max.)(5 points)
Performance :	3D Type	Outdoor Visibility	Reflectance
Performance :	-	Sunlight Readable

LG Display LD470EUP-SEA1 Interface Features

Signal Electrical :	Current Input		Voltage Input			Consumption
Signal Electrical :	670/871mA (Typ./Max.)		12.0V (Typ.)			8.0/10.4W (Typ./Max.)
Interface Features :	Position	Type	Interface
Interface Features :	-	Connector	LVDS (4 ch, 8/10-bit)
Signal Interface :	Brand	Model	Amount	Pin Pitch	Pins	Pin Assignment
	JAE	FI-RE51S-HF	1 pcs	0.5 mm	51 pins
	JAE	FI-RE41S-HF	1 pcs	0.5 mm	41 pins

LG Display LD470EUP-SEA1 Backlight Features

Backlight Features:	Type	Position	Shape	Amount	Life(Hours)	Replacement
Backlight Features:	WLED	Edge light type	-	-	50K(Typ.)	-
Interface Features :	Position	Type	WLED Driver
Interface Features :	-	Connector	With LED Driver
Interface Detail	Brand	Model	Amount	Pin Pitch	Pins	Pin Assignment
Interface Detail	YEONHO	20022WR-H14B2	1 pcs	2.0 mm	14 pins
Driver Electrical :	Current Input		Voltage Input			Consumption
Driver Electrical :	3.85A (Typ.)		24.0±1.2V			92.4W (Typ.)

LG Display LD470EUP-SEA1 Packing Features

Package Carton :	Amount	Weight	Carton Size
Package Carton :	18 pcs / box	-	1300×1140×848.5 mm (L×W×H)

Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
