320×240 115PPI 370cd/m2 Industrial Lcd Panel ISO9001 LB035Q02-TD02

Name: 320240 115PPI 370cdm2 Industrial Lcd Panel ISO9001 LB035Q02TD02
Brand: LG. LCD
Price: 1 USD

Buy cheap 320×240 115PPI 370cd/m2 Industrial Lcd Panel ISO9001 LB035Q02-TD02 product

Brand Name : LG. LCD

Model Number : LB035Q02-TD02

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 200PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LB035Q02-TD02

BRAND : LG. LCD

SIZE : 3.5 inch

BRIGHTNESS : 370CD/M2

Lamp Type : WLED

RESOLUTION : 320(RGB)×240 (QVGA) 115PPI

VIEWING ANGLEG : 65/65/50/60 (Typ.)(CR≥10)

TEMPERATURE RANGE : Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²)

Contact Now

LG. LCD LB035Q02-TD02 Application Features

Basic Information :	Brand	Model	Type	Model Alias
Basic Information :		LB035Q02-TD02	a-Si TFT-LCD , LCM	-
Reliability :	RoHS	Operating Temperature	Storage Temperature	Vibration Resistance
Reliability :	-	-20 ~ 70 °C	-30 ~ 80 °C	2.0G (19.6 m/s²)

LG. LCD LB035Q02-TD02 Mechanical Features

Panel Size :	3.5 inch
Pixel Features :	Resolution	Pixel Arrangement	Dot Pitch (W×H)	Pixel Pitch (W×H)
Pixel Features :	320(RGB)×240, QVGA	RGB Vertical Stripe	0.073×0.219 mm	0.219×0.219 mm [115PPI]
Mechanical Size :	Active Area (W×H)	Bezel Area (W×H)	Outline Dimension (W×H)	Outline Depth
Mechanical Size :	70.08×52.56 mm	72.48×55.26 mm	76.9×63.9 mm	3.15±0.15 mm
Outline Features :	Form Style	Aspect Ratio	Orientation	Shape Style
Outline Features :	Flat Rectangle	4:3 (W : H)	Landscape type
Other Features :	Panel Cover	Weight	Surface
Other Features :	-	35.0/40.0g (Typ./Max.)	Clear, Hard coating (3H)

LG. LCD LB035Q02-TD02 Optical Features

Basic Information :	Brightness	Operating Mode	Contrast Ratio
	370 cd/m² (Typ.)	TN, Normally White, Transmissive	400:1 (Typ.) (Transmissive)
	Viewing Angle(L/R/U/D)	Viewing Direction	Response Speed
	65/65/50/60 (Typ.)(CR≥10)	6 o'clock	25 (Typ.)(Tr+Td) (ms)
Dispaly Color :	Color Temperature	Color Amount	White color Chromaticity
Dispaly Color :	6638K	16.7M (6-bit + Hi-FRC)	X:0.310; Y:0.330
1931 Color Gamlt :	NTSC Ratio	sRGB Coverage	Adobe RGB Coverage
	48%	66%	50%
	DCI-P3 Coverage	Rec.2020 Coverage	Remarks
	50%	36%	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Luminance Variation :	1.20/1.40 (Typ./Max.)(9 points)

LG. LCD LB035Q02-TD02 Interface Features

Signal Electrical :	Current Input		Voltage Input			Consumption
Signal Electrical :	-		3.3/13/-9V (Typ.)(VCI/VGH/VGL)			90/100mW (Typ./Max.)
Interface Features :	Position	Type	Interface
Interface Features :	-	FPC	Digital RGB (8/18/24-bit) + SPI
Signal Interface :	Brand	Model	Amount	Pin Pitch	Pins	Pin Assignment
Signal Interface :			1 pcs	0.5 mm	60 pins

LG. LCD LB035Q02-TD02 Backlight Features

Backlight Features:	Type	Position	Shape	Amount	Life(Hours)	Replacement
Backlight Features:	WLED	Edge light type	1 string	6S1P	-	-
Interface Features :	Position	Type	WLED Driver
Interface Features :	-	Included in panel signal interface	No

LG. LCD LB035Q02-TD02 Packing Features

Package Carton :	Amount	Weight	Carton Size
Package Carton :	135 pcs / box	-	475×348×210 mm (L×W×H)

Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
