65in 3840×2160 Square Tft Panel 500cd/m2 LD650EGE-FHM1 89/89/89/89 (Typ.)(CR≥10)

Name: 65in 38402160 Square Tft Panel 500cdm2 LD650EGEFHM1 89898989 TypCR10
Brand: LG DISPLAY
Price: 1 USD

Buy cheap 65in 3840×2160 Square Tft Panel 500cd/m2 LD650EGE-FHM1 89/89/89/89 (Typ.)(CR≥10) product

Brand Name : LG DISPLAY

Model Number : LD650EGE-FHM1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 350PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LD650EGE-FHM1

BRAND : LG DISPLAY

SIZE : 65 inch

BRIGHTNESS : 500CD/M2

Lamp Type : WLED

RESOLUTION : 3840(3)×2160 [UHD] 68PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG Display LD650EGE-FHM1 Application Features

Basic Information :	Brand Name	Model Name	Type	Model Alias
Basic Information :		LD650EGE-FHM1	a-Si TFT-LCD , LCM	LD650EGE (FH)(M1)
Maximum Ratings :	RoHS	Operating Temperature	Storage Temperature	Vibration Level
Maximum Ratings :		0 ~ 50 °C	-20 ~ 60 °C

LG Display LD650EGE-FHM1 Mechanical Features

Screen Size :	65"
Pixel Features :	Pixel Number	Pixel Format	Dot Pitch (H×V)	Pixel Pitch (H×V)
Pixel Features :	3840(3)×2160, UHD	RGBW Vertical Stripe	0.124×0.372 mm	0.372×0.372 mm [68PPI]
Mechanical Size :	Display Area (H×V)	Bezel Opening (H×V)	Overall Dimension (H×V)	Overall Depth
Mechanical Size :	1428.48×803.52 mm	1430.48×808.6 mm	1452.2×830 mm	13.5 (Typ.) mm
Outline Features :	Form Shape	Aspect Ratio (H:V)	Orientation	Shape Style
Outline Features :	Flat Rectangle	16:9	Landscape type
Other Spec :	Mass	Panel Cover	Surface Treatment
Other Spec :	21.4/22.5Kgs (Typ./Max.)	-	Antiglare (Haze 1%), Hard coating (3H)

LG Display LD650EGE-FHM1 Optical Features

Basic Information :	Luminance	Work Mode	Contrast Ratio
	500 cd/m² (Typ.)	IPS, Normally Black, Transmissive	1100:1 (Typ.) (Transmissive)
	Good View at	Viewing Angle	Response Time
	Symmetry	89/89/89/89 (Min.)(CR≥10)	8 (Typ.)(G to G) (ms)
Dispaly Color :	Color Temperature:	Support Color	Color Coordinate
Dispaly Color :	9966K	1.07B (8-bit + Dithering)	X:0.281; Y:0.288
1931 Color Gamlt :	NTSC Ratio	sRGB Coverage	Adobe RGB Coverage
	69%	96%	72%
	DCI-P3 Coverage	Rec.2020 Coverage	Remarks
	72%	52%	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
White Uniformity :	1.54 (Max.)(9 points)

LG Display LD650EGE-FHM1 Backlight Features

Back-light Features:	Type	Position	Life(Hours)	Amount	Shape	Replacement
Back-light Features:	WLED	Edge light type	50K(Typ.)	-	-	-
WLED Electrical :	Input Voltage		Input Current			Power Consumption
WLED Electrical :	210.8V		180mA (Typ.)			75.9/86.1W (Typ./Max.)
Interface Features :	WLED Driver State			Physical Type		Interface Position
Interface Features :	No			Connector		-
Interface Detail	Brand Name	Model Name	Amount	Pins	Pin Pitch	Pin Configuration
Interface Detail	YEONHO		1 pcs	7 pins		BLE-7PINS-CNANCAN

LG Display LD650EGE-FHM1 Interface Features

Signal Electrical :	Input Voltage		Input Current			Power Consumption
Signal Electrical :	12.0V (Typ.)		1.28/1.67A (Typ./Max.)			15.39/20.01W (Typ./Max.)
Interface Features :	Signal Type			Physical Type		Interface Position
Interface Features :	V-by-One 8 lane			Connector
Interface Detail :	Brand Name	Model Name	Amount	Pins	Pin Pitch	Pin Configuration
Interface Detail :	JAE	FI-RE51S-HF	1 pcs	51 pins	0.5 mm

LG Display LD650EGE-FHM1 Packing Features

Package Box :	Amount	Weight	Size (L×W×H)
Package Box :	18 pcs / box	-	1700×1140×1090 mm (L×W×H)

Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
