25.0" 2560×1440 Industrial TFT Display 117PPI LM250WQ1-SSA1 89/89/89/89 (Typ.)(CR≥10)

  • 1
  • 2
  • 3

Brand Name : LG DISPLAY

Model Number : LM250WQ1-SSA1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 350PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LM250WQ1-SSA1

BRAND : LG DISPLAY

SIZE : 25.0 inch

BRIGHTNESS : 350CD/M2

Lamp Type : WLED

RESOLUTION : 2560(RGB)×1440 [Quad-HD] 117PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG Display LM250WQ1-SSA1 Application Details

Basic Info : Panel Brand   Panel Model LM250WQ1-SSA1
Diagonal Size 25.0" Application





  •
  •
Panel Type a-Si TFT-LCD , LCM Model Alias LM250WQ1 (SS)(A1)
Reliability : Operating Temp. 0 ~ 50 °C Storage Temp. -20 ~ 60 °C



LG Display LM250WQ1-SSA1 Mechanical Details

Pixel Features : Pixel Format 2560(RGB)×1440 [Quad-HD] Dot Pitch 0.0720×0.2160 mm (H×V)
Configuration RGB Vertical Stripe Pixel Pitch 0.2160×0.2160 mm (H×V) [117PPI]
Mechanical Size : Display Area 552.96×311.04 mm (H×V) Bezel Area -
Outline Dim. 565×330.7 mm (H×V) Outline Depth 12.8 (Typ.) mm
Outline Features : Form Factor Flat Rectangle Orientation Landscape type
Aspect Ratio 16:9 (H:V) Shape Style 3-side borderless
Holes & Brackets : Rear mounting poles (9-M3)
Other Features : Weight 2.80Kgs Surface Antiglare, Hard coating (3H)



LG Display LM250WQ1-SSA1 Optical Details

Basic Information : Brightness 350 cd/m² (Typ.) Contrast Ratio 1000:1 (Typ.) (Transmissive)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Optical Mode IPS, Normally Black, Transmissive
Viewing Direction Symmetry Response Time 14 (Typ.)(G to G) (ms)
Color Performance : Chromaticity Wx:0.313; Wy:0.329 Color Numbers 16.7M (8-bit)
Color Temperature 6485K White Uniformity 1.33 (Max.)(9 points)
1931 Color Gamlt : NTSC Ratio 76% sRGB 100% coverage
Adobe RGB 77% coverage DCI-P3 79% coverage
Rec.2020 57% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



LG Display LM250WQ1-SSA1 Backlight Details

Back-light Features: Lamp Shape 4 strings Lamp Type WLED Life Time 30K(Min.) (Hours)
Replacement - Amount 16S4P Position Edge light type (Bottom side)
Lamp Electrical : Voltage Input 48.8±3.2V Current Input 105/110mA (Typ./Max.)
Consumption 20.2/21.5W (Typ./Max.)
Interface Features : Type Connector Position   Lamp Driver No
Interface Detail : Brand Model Pin Pitch Pins Amount Configuration
JST BM06B-SHJS-TB(HF) 1.0 mm 6 pins 1 pcs BLE-6PINS-CCAACC



LG Display LM250WQ1-SSA1 Interface Details

Signal Systerm : LVDS (4 ch, 8-bit) Logic Voltage -
Signal Electrical : Voltage Input 10.0V (Typ.) Current Input 575/661mA (Typ./Max.)
Consumption 5.75/6.61W (Typ./Max.)
Interface Features : Type Connector Position
Connector Detail : Brand Model Pin Pitch Pins Amount Configuration
UJU IS050-C51B-C39-A 0.5 mm 51 pins 1 pcs
UJU IS050-C41B-C39-A 0.5 mm 41 pins 1 pcs



LG Display LM250WQ1-SSA1 Carton Details

Package Carton : Amount Net Weight Carton Size (L×W×H)
10 pcs / box - 710×365×448 mm






Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
