45PPI 200cd/m2 Industrial TFT Display 49in 1920×1080 LC490DUE-FJA1

Name: 45PPI 200cdm2 Industrial TFT Display 49in 19201080 LC490DUEFJA1
Brand: LG DISPLAY
Price: 1 USD

Buy cheap 45PPI 200cd/m2 Industrial TFT Display 49in 1920×1080 LC490DUE-FJA1 product

Brand Name : LG DISPLAY

Model Number : LC490DUE-FJA1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 350PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LC490DUE-FJA1

BRAND : LG DISPLAY

SIZE : 49 inch

BRIGHTNESS : 200CD/M2

Lamp Type : WLED

RESOLUTION : 1920(RGB)×1080, FHD, 45PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG Display LC490DUE-FJA1 Application Features

Basic Information :	Manufacturer	Panel Model	Panel Type	Alias
Basic Information :		LC490DUE-FJA1	a-Si TFT-LCD , LCM	LC490DUE (FJ)(A1)
Environment :	RoHS State	Operating Temp.	Storage Temp.	Vibration Level
Environment :		0 ~ 50 °C	-20 ~ 60 °C

LG Display LC490DUE-FJA1 Optical Features

Basic Information :	Luminance (cd/m²)	Viewing Angle (L/R/U/D)	Response Time (ms)
	200 (Typ.)	89/89/89/89 (Min.)(CR≥10)	9 (Typ.)(G to G)
	Best View on	Display Mode	Contrast Ratio
	Symmetry	IPS, Normally Black, Transmissive	1100 : 1 (Typ.) (Transmissive)
Dispaly Color :	Color Temperature	Display Colors	White Coordinate
Dispaly Color :	9966K	16.7M (8-bit)	X:0.281; Y:0.288
1931 Color Gamlt :	NTSC Ratio	sRGB Coverage	Adobe RGB Coverage
	69%	94%	71%
	DCI-P3 Coverage	Rec.2020 Coverage	Remarks
	71%	51%	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
White Variation :	1.67 (Max.)(9 points)

LG Display LC490DUE-FJA1 Mechanical Features

Panel Size :	49"
Pixel Features :	Pixel Format	Pixel Configuration	Pixel Pitch (mm)	Dot Pitch (mm)
Pixel Features :	1920(RGB)×1080 [FHD]	RGB Vertical Stripe	0.55926×0.55926 [45PPI]	0.18642×0.55926
Mechanical Size :	Active Area (mm)	Bezel Area (mm)	Outline Dimension (mm)	Outline Depth (mm)
Mechanical Size :	1073.78(H) × 604(V)	1077.8(H) × 608.0(V)	1108.08(H) × 656.01(V)	52.7 (Max.) mm
Outline Features :	Form Factor	Orientation	Aspect Ratio	Shape Style
Outline Features :	Flat Rectangle	Landscape type	16:9 (H:V)
Other Detail :	Weight	Panel Cover	Treatment
Other Detail :	7.90/8.50Kgs (Typ./Max.)	-	Antiglare (Haze 3%), Hard coating (2H)

LG Display LC490DUE-FJA1 Backlight Features

Lamp Features:	Type	Position	Quantity	Shape	Life(Hours)	Lamp Exchange
Lamp Features:	WLED	Direct light type	-	-	50K(Typ.)	-
WLED Electrical :	Voltage Supply		Current Supply			Power
WLED Electrical :	45.4/48.5/53.6V (Min./Typ./Max.)		300mA (Typ.)			29.1/32.2W (Typ./Max.)
Interface Features :	Position	Backlight Driver				Type
Interface Features :	-	No				Connector
Interface Detail :	Brand	Model	Pin Pitch	Pin Amount	Quantity	Configuration
Interface Detail :	YEONHO			4 pins	1 pcs

LG Display LC490DUE-FJA1 Interface Features

Panel Driving Electrical :	Voltage Supply		Current Supply			Power
Panel Driving Electrical :	12.0V (Typ.)		355/465mA (Typ./Max.)			4.5/5.9W (Typ./Max.)
Interface Features :	Position	Signal				Type
Interface Features :	-	LVDS (2 ch, 8-bit)				Connector
Connector Detail :	Brand	Model	Pin Pitch	Pin Amount	Quantity	Configuration
Connector Detail :	JAE	FI-RXE51S-HF	0.5 mm	51 pins	1 pcs

LG Display LC490DUE-FJA1 Packing Features

Package Box :	Quantity	Weight	Box Size
Package Box :	14 pcs / box	-	1300×1140×825 mm (L×W×H)

Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
