LP156WH4-TLN2 LG Display 15.6" 1366(RGB)×768 220 cd/m² INDUSTRIAL LCD DISPLAY

Name: LP156WH4TLN2 LG Display 156quot 1366RGB768 220 cdm INDUSTRIAL LCD DISPLAY
Brand: LG DISPLAY
Price: 1 USD

Buy cheap LP156WH4-TLN2 LG Display 15.6" 1366(RGB)×768 220 cd/m² INDUSTRIAL LCD DISPLAY product

Brand Name : LG DISPLAY

Model Number : LP156WH4-TLN2

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 500PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LP156WH4-TLN2

BRAND : LG DISPLAY

SIZE : 15.6 inch

BRIGHTNESS : 220CD/M2

Lamp Type : WLED

RESOLUTION : 1366(RGB)×768 (WXGA) 100PPI

VIEWING ANGLEG : 45/45/15/35 (Typ.)(CR≥10

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG Display LP156WH4-TLN2 Application Details

Basic Info :	Panel Brand		Panel Model	LP156WH4-TLN2 64 Compatible
	Diagonal Size	15.6"	Application
	Panel Type	a-Si TFT-LCD , LCM	Model Alias	LP156WH4 (TL)(N2), LGD038E
Reliability :	Operating Temp.	0 ~ 50 °C	Storage Temp.	-20 ~ 60 °C

LG Display LP156WH4-TLN2 Mechanical Details

Pixel Features :	Pixel Format	1366(RGB)×768 [WXGA]	Dot Pitch	0.084×0.252 mm (H×V)
Pixel Features :	Configuration	RGB Vertical Stripe	Pixel Pitch	0.252×0.252 mm (H×V) [100PPI]
Mechanical Size :	Display Area	344.232×193.536 mm (H×V)	Bezel Area	350.0×197.1 mm (H×V)
Mechanical Size :	Outline Dim.	359.3×209.5 mm (H×V)	Outline Depth	5.2/5.5 (Typ./Max.) mm
Outline Features :	Form Factor	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio	16:9 (H:V)	Shape Style	Wedge (PCBA Bent, T≥5.2mm)
Holes & Brackets :	Side mounting holes (8-M2) on left, right bezel
Other Features :	Weight	420g (Max.)	Surface	Glare (Haze 0%), Hard coating (3H)

LG Display LP156WH4-TLN2 Optical Details

Basic Information :	Brightness	220 cd/m² (Typ.)	Contrast Ratio	400:1 (Min.) (Transmissive)
	Viewing Angle	45/45/15/35 (Typ.)(CR≥10)	Optical Mode	TN, Normally White, Transmissive
	Viewing Direction	6 o'clock	Response Time	16 (Typ.)(Tr+Td) (ms)
Color Performance :	Chromaticity	Wx:0.313; Wy:0.329	Color Numbers	262K (6-bit)
Color Performance :	Color Temperature	6485K	White Uniformity	1.40/1.60 (Typ./Max.)(13 points)
1931 Color Gamlt :	NTSC Ratio	58%	sRGB	76% coverage
	Adobe RGB	59% coverage	DCI-P3	60% coverage
	Rec.2020	43% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LP156WH4-TLN2 Backlight Details

Back-light Features:	Lamp Shape	4 strings	Lamp Type	WLED	Life Time	12K(Min.) (Hours)
Back-light Features:	Replacement	-	Amount	4 strings	Position	Edge light type
Interface Features :	Type	Included in panel signal interface	Position	-	Lamp Driver	With LED Driver
Driver Electrical :	Voltage Input	7.0/12.0/21.0V (Min./Typ./Max.)		Current Input	300/335mA (Typ./Max.)
Driver Electrical :	Consumption	3.6/4.0W (Typ./Max.)

LG Display LP156WH4-TLN2 Interface Details

Signal Systerm :	LVDS (1 ch, 6-bit)			Logic Voltage	-
Signal Electrical :	Voltage Input	3.3V (Typ.)		Current Input	220/260mA (Typ./Max.)
Signal Electrical :	Consumption	0.7/0.9W (Typ./Max.)
Interface Features :	Type	Connector	Position
Connector Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Connector Detail :	LS Mtron	GT05Q-40S-H10-M	0.5 mm	40 pins	1 pcs	LVDS-40P1C6B-060B

LG Display LP156WH4-TLN2 Carton Details

Package Carton :	Amount	Net Weight	Carton Size (L×W×H)
Package Carton :	22 pcs / box	-	478×365×288 mm

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
