LM270WF9-SSA1 LG Display 27.0" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY

Product Categories
Sapientia Display Co.,LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

LM270WF9-SSA1 LG Display 27.0" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY

Brand Name : LG DISPLAY

Model Number : LM270WF9-SSA1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 500PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LM270WF9-SSA1

BRAND : LG DISPLAY

SIZE : 27.0INCH

BRIGHTNESS : 400CD/M2

Lamp Type : WLED

RESOLUTION : 1920(RGB)×1080 [FHD] 81PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG Display LM270WF9-SSA1 Application Details

Basic Detail : Manufacturer   Model Name LM270WF9-SSA1
Panel Type a-Si TFT-LCD , LCM Another Name LM270WF9 (SS)(A1)
Panel Size 27.0 inch Designed For







  •
  •
  •
  •
Maximum Ratings : OP Temperature 0 ~ 50 °C ST Temperature -20 ~ 60 °C



LG Display LM270WF9-SSA1 Application Details

Basic Detail : Manufacturer   Model Name LM270WF9-SSA1
Panel Type a-Si TFT-LCD , LCM Another Name LM270WF9 (SS)(A1)
Panel Size 27.0 inch Designed For







  •
  •
  •
  •
Maximum Ratings : OP Temperature 0 ~ 50 °C ST Temperature -20 ~ 60 °C



LG Display LM270WF9-SSA1 Optical Details

Basic Information : Luminance 400 cd/m² (Typ.) Contrast Ratio 1200 : 1 (Typ.) (Transmissive)
Good View at Symmetry Response Speed 5 (Typ.)(G to G) (ms)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10)  Operating Mode IPS, Normally Black, Transmissive
Color Performance : Chromaticity Wx:0.313; Wy:0.329 Support Color 16.7M (8-bit)
Color Temperature 6485K White Uniformity 1.33 (Max.)(9 points)

LG Display LM270WF9-SSA1 Mechanical Details

Pixel Features : Number of Pixel 1920(RGB)×1080 [FHD] Arrangement RGB Vertical Stripe
Dot Pitch(W×H) 0.1038×0.3114 mm Pixel Pitch(W×H) 0.3114×0.3114 mm [81PPI]
Physical Size : Active Viewing 597.888(W)×336.312(H) mm Overall Dim. 608.8(W)×355.1(H) mm
Bezel Opening - Overall Depth 9.8/15.4 (Typ./Max.) mm
Outline Features : Form Shape Flat Rectangle Orientation Landscape type
Aspect Ratio(W:H) 16:9 Shape Style 3-side borderless
Fixation : Rear mounting holes
Other Detail : Mass 2.35/2.47Kgs (Typ./Max.) Surface Hard coating (3H), Antireflection



LG Display LM270WF9-SSA1 Interface Details

Signal Electrical : Input Current 605/756mA (Typ./Max.) Input Voltage 10.0V (Typ.)
Consumption 6.05W (Typ.) Signal Interface eDP (4 Lanes)
Interface Features : Position - Physical Type Connector
Signal Interface : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
LS Mtron GT05Q-30S-H10-MN 1 pcs 0.5 mm 30 pins EDP-30P4L-050B



LG Display LM270WF9-SSA1 Lightting Details

Lamp Features: Lamp Shape - Lamp Type WLED Position Edge light type (Bottom side)
Exchange - Amount - Life 30K(Min.) (Hours)
Interface Features : Position   Physical Type Connector
Interface Detail : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
YEONHO 10035WS-H06D 1 pcs 1.0 mm 6 pins BLE-6PINS-CCAACC
Backlight Driver : No



LG Display LM270WF9-SSA1 Packing Details

Package Box : Amount Size (L×W×H) Weight
10 pcs / box 365×710×448 mm -



 FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.





LM270WF9-SSA1 LG Display 27.0" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY
